SIRIUS 3RT2025-1BB40 Power Contactor 3RT2025-1BB40, 24 VDC Coil, 17 A Max Load, 3NO, 3 Poles
Custom_Product_Images_Illustration
SIRIUS 3RT2025-1BB40 Power Contactor 3RT2025-1BB40, 24 VDC Coil, 17 A Max Load, 3NO, 3 Poles
SKU610373
MFGR #3RT20251BB40
Your Cost: $180.40/ea
List: SIEMENS 3RT20251BB40 CONTACTOR AC-3 7.5KW/400V 1NO+1NC DC
SIEMENS 3RT20251BB40 CONTACTOR AC-3 7.5KW/400V 1NO+1NC DC
Alternate Catalog Number 3RT2025-1BB40 ARRA Compliant C Brand Siemens Buy American Compliant C Catalog Number 3RT20251BB40 Coil Power Rating 5.9 W Coil Voltage 24 VDC Contact Configuration 1NO-1NC Country of Origin DE Currency USD Dimensions 85 mm H x 45 mm W x 107 mm D Enclosure Type IP20 EU RoHS Indicator C Gross Volume Per Pack 34.83 Gross Volume UOM in Gross Weight Per Pack 1.3300 lb Gross Weight per Pack Metric 0.60 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536490065 Height 3.6000 in Height [Metric] 9.1440 cm Length 4.5000 in Length [Metric] 11.4300 cm Manufacturer Siemens Maximum Load Current 17 A Mounting Type DIN Rail/Snap-On/Threaded Number of Auxiliary Contacts 2 Number Of Poles 3 Operating Cycles 10000000 Operating Temperature -25 to 60 Replaced Catalog Number 3RT1025-1BB40 Returnable Y Size S0 Standards RoHS CompliantCCC CertifiedCSA CertifiedUL ListedEAC ApprovedC-TickCE CertifiedABS ApprovedBureau Veritas CertifiedLRS ListedPRS CertifiedRINA CertifiedRMRS ApprovedDNV-GL ApprovedVDE Approved Stock Status NORMALLY STOCKED Terminal Type Screw Type Standard UNSPSC 39121529 UPC 11 66264391434 UPC 12 662643914344 Wattage 7.5 kW Width 2.1500 in Width [Metric] 5.4610 cm 5.9 W (closing/holding) magnet coil at DC Can be tilted forward and backward by +/- 22.5 deg on vertical mounting surface Screw and snap-on mounting onto 35 mm standard mounting rail 10000000 of contactor/typical, 5000000 of the contactor with added electronics compatible auxiliary switch block typical, 10000000 of the contactor with added auxiliary switch block typical
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | 3RT2025-1BB40 |
| ARRA Compliant | C |
| Brand | Siemens |
| Buy American Compliant | C |
| Catalog Number | 3RT20251BB40 |
| Coil Power Rating | 5.9 W |
| Coil Voltage | 24 VDC |
| Contact Configuration | 1NO-1NC |
| Country of Origin | DE |
| Currency | USD |
| Dimensions | 85 mm H x 45 mm W x 107 mm D |
| Enclosure Type | IP20 |
| EU RoHS Indicator | C |
| Gross Volume Per Pack | 34.83 |
| Gross Volume UOM | in |
| Gross Weight Per Pack | 1.3300 lb |
| Gross Weight per Pack Metric | 0.60 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536490065 |
| Height | 3.6000 in |
| Height [Metric] | 9.1440 cm |
| Length | 4.5000 in |
| Length [Metric] | 11.4300 cm |
| Manufacturer | Siemens |
| Maximum Load Current | 17 A |
| Mounting Type | DIN Rail/Snap-On/Threaded |
| Number of Auxiliary Contacts | 2 |
| Number Of Poles | 3 |
| Operating Cycles | 10000000 |
| Operating Temperature | -25 to 60 |
| Replaced Catalog Number | 3RT1025-1BB40 |
| Returnable | Y |
| Size | S0 |
| Standards | RoHS CompliantCCC CertifiedCSA CertifiedUL ListedEAC ApprovedC-TickCE CertifiedABS ApprovedBureau Veritas CertifiedLRS ListedPRS CertifiedRINA CertifiedRMRS ApprovedDNV-GL ApprovedVDE Approved |
| Stock Status | NORMALLY STOCKED |
| Terminal Type | Screw |
| Type | Standard |
| UNSPSC | 39121529 |
| UPC 11 | 66264391434 |
| UPC 12 | 662643914344 |
| Wattage | 7.5 kW |
| Width | 2.1500 in |
| Width [Metric] | 5.4610 cm |
| 5.9 W (closing/holding) magnet coil at DC |
| Can be tilted forward and backward by +/- 22.5 deg on vertical mounting surface |
| Screw and snap-on mounting onto 35 mm standard mounting rail |
| 10000000 of contactor/typical, 5000000 of the contactor with added electronics compatible auxiliary switch block typical, 10000000 of the contactor with added auxiliary switch block typical |
