Panduit® UGB2/0-414-6 Universal Ground Rod, 14 to 4 AWG, 4.92 in OAL, Copper, Tin Plated
Custom_Product_Images_Illustration
Panduit® UGB2/0-414-6 Universal Ground Rod, 14 to 4 AWG, 4.92 in OAL, Copper, Tin Plated
SKU658802
MFGR #UGB2/0-414-6
Your Cost: $49.55/ea
Panduit® Ground Rod, Universal, 14 to 4 AWG Nominal Size, 4.92 in Overall Length, Copper, Tin Plated
Panduit® Ground Rod, Universal, 14 to 4 AWG Nominal Size, 4.92 in Overall Length, Copper, Tin Plated
ARRA Compliant Y Buy American Compliant Y Cable Main 2/0 AWG Catalog Number UGB2/0-414-6 Clamp Material Copper Color Silver Conductor Material Copper Connection Type Lug Country of Origin MEX Currency USD EU RoHS Indicator Y Finish Electrolytic/Tin Plated Gross Volume UOM CF Gross Volume UOM Metric m3 Gross Weight Per Pack 0.2780 lb Gross Weight per Pack Metric 0.13 Gross Weight UOM Metric kg Height 0.70 in Height [Metric] 1.7780 cm Length 5.65 in Length [Metric] 14.3510 cm Material Copper Returnable Y Standard UL 467 and CSA certified 22.2 no.41 Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL 467UL 508ACSA 22.2 Sub Brand StructuredGround?„? Type Grounding Busbar UNSPSC 46182103 UPC 11 07498340222 UPC 12 07498340222 Width 4.00 in Width [Metric] 10.1600 cm Stock Status NORMALLY STOCKED Brand Panduit® Manufacturer Panduit® Bar Height 0.48 in Bar Length 4.92 in Bar Width 0.62 in Works with all types of wire termination methods including stripped wire, ferrules, terminals and compression or mechanical connectors, compatible with over 140 Panduit® connectors In addition to surface mounting, two mounting stand-off options are available, one that bonds to the mounting surface and one that isolates from the mounting surface, both options provide additional finger wiring space in tight places The unique shape of the universal ground bar allows more surface contact between the wire connectors and the ground bar Universal ground bar accepts 4 to 14 AWG wire in 6 wire ports and up to a 2/0 AWG main equipment grounding conductor with a compression or mechanical connector 6-port UGB mounted on isolation stand-offs with the equipment grounding conductor terminated in an anti-rotational, copper mechanical connector Ground bars and bonding stand-offs precision machined from 110 electrolytic copper with a 99.9% copper content and then tin plated for additional corrosion resistance Top of ground bar accepts ring terminals, compression connectors or mechanical connectors with a 1/4 in stud hole size and maximum width of 0.55 in Each part is provided with all fasteners required for terminating wires and for each mounting option
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Media
- Substitute Products
| ARRA Compliant | Y |
| Buy American Compliant | Y |
| Cable Main | 2/0 AWG |
| Catalog Number | UGB2/0-414-6 |
| Clamp Material | Copper |
| Color | Silver |
| Conductor Material | Copper |
| Connection Type | Lug |
| Country of Origin | MEX |
| Currency | USD |
| EU RoHS Indicator | Y |
| Finish | Electrolytic/Tin Plated |
| Gross Volume UOM | CF |
| Gross Volume UOM Metric | m3 |
| Gross Weight Per Pack | 0.2780 lb |
| Gross Weight per Pack Metric | 0.13 |
| Gross Weight UOM Metric | kg |
| Height | 0.70 in |
| Height [Metric] | 1.7780 cm |
| Length | 5.65 in |
| Length [Metric] | 14.3510 cm |
| Material | Copper |
| Returnable | Y |
| Standard | UL 467 and CSA certified 22.2 no.41 |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL 467UL 508ACSA 22.2 |
| Sub Brand | StructuredGround?„? |
| Type | Grounding Busbar |
| UNSPSC | 46182103 |
| UPC 11 | 07498340222 |
| UPC 12 | 07498340222 |
| Width | 4.00 in |
| Width [Metric] | 10.1600 cm |
| Stock Status | NORMALLY STOCKED |
| Brand | Panduit® |
| Manufacturer | Panduit® |
| Bar Height | 0.48 in |
| Bar Length | 4.92 in |
| Bar Width | 0.62 in |
| Works with all types of wire termination methods including stripped wire, ferrules, terminals and compression or mechanical connectors, compatible with over 140 Panduit® connectors |
| In addition to surface mounting, two mounting stand-off options are available, one that bonds to the mounting surface and one that isolates from the mounting surface, both options provide additional finger wiring space in tight places |
| The unique shape of the universal ground bar allows more surface contact between the wire connectors and the ground bar |
| Universal ground bar accepts 4 to 14 AWG wire in 6 wire ports and up to a 2/0 AWG main equipment grounding conductor with a compression or mechanical connector |
| 6-port UGB mounted on isolation stand-offs with the equipment grounding conductor terminated in an anti-rotational, copper mechanical connector |
| Ground bars and bonding stand-offs precision machined from 110 electrolytic copper with a 99.9% copper content and then tin plated for additional corrosion resistance |
| Top of ground bar accepts ring terminals, compression connectors or mechanical connectors with a 1/4 in stud hole size and maximum width of 0.55 in |
| Each part is provided with all fasteners required for terminating wires and for each mounting option |
