Panduit® LCDX500-12-6 LCDX 2-Hole Compression Lug Connector With Inspection Window, 500 kcmil/535.3 kcmil Copper Conductor, P99
Custom_Product_Images_Illustration
Panduit®
Panduit® LCDX500-12-6 LCDX 2-Hole Compression Lug Connector With Inspection Window, 500 kcmil/535.3 kcmil Copper Conductor, P99
SKU484295
MFGR #LCDX500-12-6
Your Cost: $81.2401/ea($8,124.01 / c)
Panduit® Compression Lug Connector, 2-Hole, Series: LCDX, Copper Conductor, 500 kcmil/535.3 kcmil Conductor, Die Code: P99, 35 kVAC, 1/2 in Stud, Standard/Straight Tongue, 1.89 in W x 0.26 in THK Tongue, 5.26 in Overall Length, Standard, 1.48 in L Barrel, 1-3/4 in Hole Spacing, 1-9/16 in Wire Stripe Length, 90 deg C, Copper, Pink
Panduit® Compression Lug Connector, 2-Hole, Series: LCDX, Copper Conductor, 500 kcmil/535.3 kcmil Conductor, Die Code: P99, 35 kVAC, 1/2 in Stud, Standard/Straight Tongue, 1.89 in W x 0.26 in THK Tongue, 5.26 in Overall Length, Standard, 1.48 in L Barrel, 1-3/4 in Hole Spacing, 1-9/16 in Wire Stripe Length, 90 deg C, Copper, Pink
ARRA Compliant Y Barrel Size 1.03 in ID x 1.3 in OD x 1.48 in L Barrel Type Standard with Inspection Window Buy American Compliant Y Catalog Number LCDX500-12-6 Color Pink Country of Origin MEX Currency USD EU RoHS Indicator Y Gross Volume UOM CF Gross Volume UOM Metric m3 Gross Weight Per Pack 0.8200 lb Gross Weight per Pack Metric 2.24 Gross Weight UOM Metric kg Height 3.45 in Height [Metric] 8.7630 cm Length 8.25 in Length [Metric] 20.9550 cm Mounting 1 9/16 Mounting Hole Size 1-9/16 in Number Of Holes 2 Overall Length 5.26 in Returnable Y Series LCDX Size 500 kcmil Class G, H, I, K, M and 535.3 kcmil DLO Specifications 1.56 in L Wire Strip, 1-3/4 in Stud Hole Spacing Standard CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164 Standards ARRA CompliantBuy American Act CompliantRoHS CompliantABS ApprovedCSA C22.2 No. 65-03UL 486A-486B File No. E52164UL Listed Sub Brand Pan-Lug?„? Temperature Rating 90 °C Tongue Size 1.89 in W x 0.26 in THK Tongue Type Standard Straight Type Compression Connectors - Lugs UNSPSC 39121405 UPC 11 07498343647 UPC 12 07498343647 Voltage Rating 35 V Width 4.35 in Width [Metric] 11.0490 cm Stock Status NONSTOCK Brand Panduit® Manufacturer Panduit® Conductor Size 500 kcmil Class G, H, I, K, M, 535.3 kcmil DLO Conductor Type Copper Die Code P99 Material Tin-Plated Copper Stud Size 1/2 in Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V Tin plated to inhibit corrosion Color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection Can be used with code conductor and flex conductor class G, H, I, K, M and Diesel Locomotive Generously beveled wire entry prevents bent back strands when inserting conductor into barrel Inspection window to visually assure full conductor insertion American bureau of shipping approved 500 kcmil (Class G, H, I, K, M)/535.3 kcmil (diesel locomotive)
