Milbank®
Milbank® U5882-X-KK-PED 200A 4T RL OU 2
Custom_Product_Images_Illustration
Milbank®
Milbank® U5882-X-KK-PED 200A 4T RL OU 2
SKU776103
MFGR #U5882-X-KK-PED
Your Cost: $1,357.18/ea
List: 4 TERM RNGLS LRG CLS PLT HRN BYPS 2 POS 2-200 AMP MN BRKR PROV PED MNT PROV
4 TERM RNGLS LRG CLS PLT HRN BYPS 2 POS 2-200 AMP MN BRKR PROV PED MNT PROV
Application Meter Socket With Main ARRA Compliant C Buy American Compliant C Bypass Type Horn bypass Cable Entry Overhead or Underground Catalog Number U5882-X-KK-PED Country of Origin USA Currency USD Cutout Size Breaker Provision Enclosure G90 Galvanized Steel with Powder Coat Finish Equipment Ground Ground Lug EU RoHS Indicator C Frequency Rating 60 Hz Gross Weight Per Pack 60.0000 lb Gross Weight per Pack Metric 27.22 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536908030 Height 30.00 in Height [Metric] 76.2000 cm Hub Opening Large Closing Plate Insulation Glass Polyester Jaw Quantity 4 Terminal Length 5.12 in Length [Metric] 13.0175 cm Mounting Surface Mount Number Of Cutouts 0 Number of Meter Positions 2 Positions Size 5.125L x 26.5W x 30H Standard UL Listed;Type 3R Terminal 3/8 Inch Stud Type Ringless Meter Socket UNSPSC 39121102 UPC 11 78457253818 UPC 12 78457253818 Width 26.50 in Width [Metric] 67.3100 cm Stock Status NONSTOCK Brand Milbank® Manufacturer Milbank Manufacturing Amperage Rating 200 Continuous Ampere Phase 1 Voltage Rating 240 VAC Meter Socket With Main
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Substitute Products
| Application | Meter Socket With Main |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Bypass Type | Horn bypass |
| Cable Entry | Overhead or Underground |
| Catalog Number | U5882-X-KK-PED |
| Country of Origin | USA |
| Currency | USD |
| Cutout Size | Breaker Provision |
| Enclosure | G90 Galvanized Steel with Powder Coat Finish |
| Equipment Ground | Ground Lug |
| EU RoHS Indicator | C |
| Frequency Rating | 60 Hz |
| Gross Weight Per Pack | 60.0000 lb |
| Gross Weight per Pack Metric | 27.22 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536908030 |
| Height | 30.00 in |
| Height [Metric] | 76.2000 cm |
| Hub Opening | Large Closing Plate |
| Insulation | Glass Polyester |
| Jaw Quantity | 4 Terminal |
| Length | 5.12 in |
| Length [Metric] | 13.0175 cm |
| Mounting | Surface Mount |
| Number Of Cutouts | 0 |
| Number of Meter Positions | 2 Positions |
| Size | 5.125L x 26.5W x 30H |
| Standard | UL Listed;Type 3R |
| Terminal | 3/8 Inch Stud |
| Type | Ringless Meter Socket |
| UNSPSC | 39121102 |
| UPC 11 | 78457253818 |
| UPC 12 | 78457253818 |
| Width | 26.50 in |
| Width [Metric] | 67.3100 cm |
| Stock Status | NONSTOCK |
| Brand | Milbank® |
| Manufacturer | Milbank Manufacturing |
| Amperage Rating | 200 Continuous Ampere |
| Phase | 1 |
| Voltage Rating | 240 VAC |
| Meter Socket With Main |
