Meltric Decontactor™ 39-24033-K07 DR250 Standard Duty Pin and Sleeve Receptacle, 250 VAC, 250 A, 3 Poles, 4 Wires, Blue
Meltric Decontactor™ 39-24033-K07 DR250 Standard Duty Pin and Sleeve Receptacle, 250 VAC, 250 A, 3 Poles, 4 Wires, Blue
SKU1388550
MFGR #39-24033-K07
Your Cost: $1,717.46/ea
List: DR Series plugs and receptacles provide safe, economical and robust connections for applications up to 400A. Some DR models are non-current interrupting rated, while others are suitable for current interruption on resistive loads. The DR's spring-loaded, silver-nickel butt contacts and dead front construction provide more consistent and reliable connections and significant improvements in operator safety compared to competitive devices.
DR Series plugs and receptacles provide safe, economical and robust connections for applications up to 400A. Some DR models are non-current interrupting rated, while others are suitable for current interruption on resistive loads. The DR's spring-loaded, silver-nickel butt contacts and dead front construction provide more consistent and reliable connections and significant improvements in operator safety compared to competitive devices.
Catalog Number 39-24033-K07 Country of Origin USA Dimensions 5.16 in Dia x 5.81 in L Enclosure IP54/IP55 Frequency Rating 50 Hz Gross Weight Per Pack 6.6700 lb Material Metal NEMA Rating NEMA 3R Number Of Poles 3 Series DR250 Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL 1682CSA 182.1CE CertifiedIEC Certified Temperature Rating -40 to 140 °F Terminal Type Screw Type Standard Duty UNSPSC 39121406 UPC 11 78447461163 Stock Status NONSTOCK Brand MELTRIC Manufacturer Meltric Corporation Amperage Rating 250 A Color Blue Number of Wires 4 Voltage Rating 110/130 VAC With Ground, Short Circuit Rating 10 KAMP High amperage capacity Up to 6 auxiliary contacts Spring assisted screw terminals patented design assures ''tighten and forget'' confidence Spring loaded butt-style contacts ensures optimal contact force and superior electrical performance over thousands of operations Lid provides Type 3R water protection for additional protection from harsh environments OFF button press to de-energize and provides push button circuit disconnection Dead front/safety shutter assures safety by preventing user access to live parts 10 kA short circuit rated
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Catalog Number | 39-24033-K07 |
| Country of Origin | USA |
| Dimensions | 5.16 in Dia x 5.81 in L |
| Enclosure | IP54/IP55 |
| Frequency Rating | 50 Hz |
| Gross Weight Per Pack | 6.6700 lb |
| Material | Metal |
| NEMA Rating | NEMA 3R |
| Number Of Poles | 3 |
| Series | DR250 |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL 1682CSA 182.1CE CertifiedIEC Certified |
| Temperature Rating | -40 to 140 °F |
| Terminal Type | Screw |
| Type | Standard Duty |
| UNSPSC | 39121406 |
| UPC 11 | 78447461163 |
| Stock Status | NONSTOCK |
| Brand | MELTRIC |
| Manufacturer | Meltric Corporation |
| Amperage Rating | 250 A |
| Color | Blue |
| Number of Wires | 4 |
| Voltage Rating | 110/130 VAC |
| With Ground, Short Circuit Rating 10 KAMP |
| High amperage capacity |
| Up to 6 auxiliary contacts |
| Spring assisted screw terminals patented design assures ''tighten and forget'' confidence |
| Spring loaded butt-style contacts ensures optimal contact force and superior electrical performance over thousands of operations |
| Lid provides Type 3R water protection for additional protection from harsh environments |
| OFF button press to de-energize and provides push button circuit disconnection |
| Dead front/safety shutter assures safety by preventing user access to live parts |
| 10 kA short circuit rated |
