Meltric Decontactor™ 37-68043 DS60 Pin and Sleeve Inlet, 480 VAC, 60 A, 3 Poles, Blue
Pin & Sleeve Inlets
199853
MFG #: 37-68043
MELTRIC
403.66000
/ ea
DS series Decontactors provide a useful combination of capacity and ruggedness. DS are often used to connect motors and welders in the metals, quarry, automotive, and mining industries. They are designed for applications requiring large wiring capacities. The DSs environmental rating is achieved as soon as the plug and receptacle are fully engaged, making them an excellent choice for outdoor applications where rainproof performance is required.
- Features
| Enclosure NEMA 3R, IP54/IP55, Wiring Capacity 10 To 2 AWG, Horsepower Rating 20 HP At 480 V 3 Phase, Polarity 3 Pole, Ground, Short Circuit Rating 100 KAMP |
| Switch and horsepower rated (AC only |
| 65 to 100 kA short circuit rated |
| Up to 200 A amperage rating |
| Up to 4 auxiliary contacts |
| Fiberglass reinforced thermoplastic polyester material offers great resistance to impact, corrosion and harsh environmental conditions |
| Solid silver nickel contact surfaces provide superior conductivity, durability and corrosion resistance |
| 10 to 2 AWG wiring capacity |
| 3 hp at 120 VAC, 5 hp at 240 VAC 1-phase, 10 hp at 208/240 VAC, 20 hp at 480 VAC, 25 hp at 480/600 VAC 3-phase horsepower rating |
