McGill® 41250004N 4125 Toggle Switch, 125 VAC/VDC, 10/5 A, 1/4 hp, SPST
Custom_Product_Images_Illustration
McGill® 41250004N 4125 Toggle Switch, 125 VAC/VDC, 10/5 A, 1/4 hp, SPST
SKU573864
MFGR #41250004N
Your Cost: $23.99/ea
McGill® Toggle Switch, Series: 4125, 125 VAC/VDC, 10/5 A, 1/4 hp, SPST, 1 Pole, Toggle, Surface, Wire Lead Terminal, Phenolic, 0.89 in L x 0.52 in W x 1.72 in H
McGill® Toggle Switch, Series: 4125, 125 VAC/VDC, 10/5 A, 1/4 hp, SPST, 1 Pole, Toggle, Surface, Wire Lead Terminal, Phenolic, 0.89 in L x 0.52 in W x 1.72 in H
Action Maintained Actuator Toggle Application Marine, food service, generator, industrial control and office automation markets ARRA Compliant N Buy American Compliant N Catalog Number 41250004N Connection 6" Lead Wire Country of Origin MX Currency USD Dimensions 0.89 in L x 0.52 in W x 1.72 in H EU RoHS Indicator C Gross Weight Per Pack 0.6500 lb Gross Weight per Pack Metric 0.30 Gross Weight UOM Metric kg Height 2.50 in Height [Metric] 6.3500 cm Length 5.00 in Length [Metric] 12.7000 cm Material Phenolic Mounting Nickel Plated Hex Nut and Knurled Nut Number Of Poles 1 Series 4125 Size .89 long x .52 wide in Standard UL Recognized Component. UL File Number E335442, UL Standard: 1054, Guide WORY2, CSA File Number: 249055, CSA Standard: C22.2 No.55, RoHS Compliant Standards RoHS CompliantUL File No. E335442UL Standard 1054Guide WORY2CSA File No. 249055CSA C22.2 No.55UL Listed Switch Type Toggle Terminal Type Lead Wire Type 4125 Seeries Single Pole Toggle Switch UNSPSC 39122211 UPC 11 03628300144 UPC 12 036283001441 Width 6.00 in Width [Metric] 15.2400 cm Stock Status NONSTOCK Brand McGill® Manufacturer McGill Amperage Rating 10 A Contact Configuration ON -- OFF Power Rating 1/4 hp Voltage Rating 125 VAC//VDC Marine, food service, generator, industrial control and office automation markets Appropriate for use in low voltage Vdc applications. Base: phenolic, Bat handle: Nickel Plated Brass, Bushing: Nickel Plated Brass Ruggedly constructed with metallic toggle and threaded bushing to ensure extended service life Appropriate for use in low voltage DC applications Indicating plate is furnished for maintained ON-OFF circuits Mounting hardware consists of nickel plated hex nut and knurled nut Phenolic base, nickel plated brass bat handle and bushing 1/2 in hole mounting ON/OFF (maintained) 6 in wire leads
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Action | Maintained |
| Actuator | Toggle |
| Application | Marine, food service, generator, industrial control and office automation markets |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | 41250004N |
| Connection | 6" Lead Wire |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 0.89 in L x 0.52 in W x 1.72 in H |
| EU RoHS Indicator | C |
| Gross Weight Per Pack | 0.6500 lb |
| Gross Weight per Pack Metric | 0.30 |
| Gross Weight UOM Metric | kg |
| Height | 2.50 in |
| Height [Metric] | 6.3500 cm |
| Length | 5.00 in |
| Length [Metric] | 12.7000 cm |
| Material | Phenolic |
| Mounting | Nickel Plated Hex Nut and Knurled Nut |
| Number Of Poles | 1 |
| Series | 4125 |
| Size | .89 long x .52 wide in |
| Standard | UL Recognized Component. UL File Number E335442, UL Standard: 1054, Guide WORY2, CSA File Number: 249055, CSA Standard: C22.2 No.55, RoHS Compliant |
| Standards | RoHS CompliantUL File No. E335442UL Standard 1054Guide WORY2CSA File No. 249055CSA C22.2 No.55UL Listed |
| Switch Type | Toggle |
| Terminal Type | Lead Wire |
| Type | 4125 Seeries Single Pole Toggle Switch |
| UNSPSC | 39122211 |
| UPC 11 | 03628300144 |
| UPC 12 | 036283001441 |
| Width | 6.00 in |
| Width [Metric] | 15.2400 cm |
| Stock Status | NONSTOCK |
| Brand | McGill® |
| Manufacturer | McGill |
| Amperage Rating | 10 A |
| Contact Configuration | ON -- OFF |
| Power Rating | 1/4 hp |
| Voltage Rating | 125 VAC//VDC |
| Marine, food service, generator, industrial control and office automation markets |
| Appropriate for use in low voltage Vdc applications. Base: phenolic, Bat handle: Nickel Plated Brass, Bushing: Nickel Plated Brass |
| Ruggedly constructed with metallic toggle and threaded bushing to ensure extended service life |
| Appropriate for use in low voltage DC applications |
| Indicating plate is furnished for maintained ON-OFF circuits |
| Mounting hardware consists of nickel plated hex nut and knurled nut |
| Phenolic base, nickel plated brass bat handle and bushing |
| 1/2 in hole mounting |
| ON/OFF (maintained) |
| 6 in wire leads |
