Marathon® F30A2B Standard Fuse Block and Holder, 250 VAC/VDC, 30 A, 14 to 6 AWG Wire, 2 Poles
Marathon® F30A2B Standard Fuse Block and Holder, 250 VAC/VDC, 30 A, 14 to 6 AWG Wire, 2 Poles
SKU28591
MFGR #F30A2B
Your Cost: $63.60/ea
Marathon® Fuse Block and Holder, Standard, 250 VAC/VDC, 30 A, 2 Poles, Class: H, Box Lug, 14 to 6 AWG Wire, Panel Mount, 2 in Fuse Length, 9/16 in Fuse Dia, -40 to 257 deg F, Thermoplastic, 3 in H x 1.91 in W x 1.38 in D
Marathon® Fuse Block and Holder, Standard, 250 VAC/VDC, 30 A, 2 Poles, Class: H, Box Lug, 14 to 6 AWG Wire, Panel Mount, 2 in Fuse Length, 9/16 in Fuse Dia, -40 to 257 deg F, Thermoplastic, 3 in H x 1.91 in W x 1.38 in D
Catalog Number F30A2B Class H Connection Type Box Lug Country of Origin USA Dimensions 3 in H x 1.91 in W x 1.38 in D Fuse Diameter 9/16 in Fuse Length 2 in Gross Weight Per Pack 1 lb Material Thermoplastic Mounting Type Panel Number Of Poles 2 Standards UL Listed, CSA Certified, CE Certified, RoHS Compliant Temperature Rating -40 to 257 °F Type Standard UNSPSC 39121624 UPC 11 78433710080 UPC 12 78433710080 Stock Status NONSTOCK Brand Marathon® Manufacturer Marathon Special Products Amperage Rating 30 A Voltage Rating 250 VAC/VDC Wire Size 14 to 6 AWG Features: ; Accessories: Cover: CHR230; Glass-Filled Polycarbonate (Thermoplastic); 125 ° C (UL RTI), Flammability Rating UL 94 V-0, UL Listed File No. JDVS2.181825; DIN Rail Adapter: DIN R-1; Wire Range: - 14 AWG; Fuse Size: 9/16 IN Diameter X 2 IN Length; Electrical Ratings: 0 - 30 AMP Max (Amperage Rating Based On Maximum Fuse Rating For That Physical Size); Copper Wire Only; 250 VAC/DC; Approved For 10000 AMP Withstand Rating; Mechanical Ratings: Insulator Base Temperature Rating: -40 ° C/F To 125 ° C (257 ° F) UL RTI; Flammability Rating Of Insulator Base: UL 94 V-0; Touch Protection: IP-20 (IEC 60529) With Optional Cover CHR230; Use Outside These Ratings Needs To Be Judged In The End-Use A; Wire Strip Length: 7/16 IN; Number Of Poles: 2; Panel Mountable: #10 Fastener, Torque 25 - 30 IN-LB 14 to 6 AWG copper Copper alloy and tin plated fuse clip High conductivity aluminum and tin plated box connector Steel and nickel plated terminal set screws Steel and zinc plated connector mounting screws IP-20 touch protection Commonly used fuses in this holder A2Y, CRN, NLN, NON, NRN, OT, OTN, RLN, RF Flammability rating of insulator base UL94V-0 Approved for 10000 A withstand rating
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Catalog Number | F30A2B |
| Class | H |
| Connection Type | Box Lug |
| Country of Origin | USA |
| Dimensions | 3 in H x 1.91 in W x 1.38 in D |
| Fuse Diameter | 9/16 in |
| Fuse Length | 2 in |
| Gross Weight Per Pack | 1 lb |
| Material | Thermoplastic |
| Mounting Type | Panel |
| Number Of Poles | 2 |
| Standards | UL Listed, CSA Certified, CE Certified, RoHS Compliant |
| Temperature Rating | -40 to 257 °F |
| Type | Standard |
| UNSPSC | 39121624 |
| UPC 11 | 78433710080 |
| UPC 12 | 78433710080 |
| Stock Status | NONSTOCK |
| Brand | Marathon® |
| Manufacturer | Marathon Special Products |
| Amperage Rating | 30 A |
| Voltage Rating | 250 VAC/VDC |
| Wire Size | 14 to 6 AWG |
| Features: ; Accessories: Cover: CHR230; Glass-Filled Polycarbonate (Thermoplastic); 125 ° C (UL RTI), Flammability Rating UL 94 V-0, UL Listed File No. JDVS2.181825; DIN Rail Adapter: DIN R-1; Wire Range: - 14 AWG; Fuse Size: 9/16 IN Diameter X 2 IN Length; Electrical Ratings: 0 - 30 AMP Max (Amperage Rating Based On Maximum Fuse Rating For That Physical Size); Copper Wire Only; 250 VAC/DC; Approved For 10000 AMP Withstand Rating; Mechanical Ratings: Insulator Base Temperature Rating: -40 ° C/F To 125 ° C (257 ° F) UL RTI; Flammability Rating Of Insulator Base: UL 94 V-0; Touch Protection: IP-20 (IEC 60529) With Optional Cover CHR230; Use Outside These Ratings Needs To Be Judged In The End-Use A; Wire Strip Length: 7/16 IN; Number Of Poles: 2; Panel Mountable: #10 Fastener, Torque 25 - 30 IN-LB |
| 14 to 6 AWG copper |
| Copper alloy and tin plated fuse clip |
| High conductivity aluminum and tin plated box connector |
| Steel and nickel plated terminal set screws |
| Steel and zinc plated connector mounting screws |
| IP-20 touch protection |
| Commonly used fuses in this holder A2Y, CRN, NLN, NON, NRN, OT, OTN, RLN, RF |
| Flammability rating of insulator base UL94V-0 |
| Approved for 10000 A withstand rating |
