Marathon® 1421572 142 Power Splicer/Distribution Block, 600 VAC/VDC, 175 A, 1 Pole, 14 to 2/0 AWG Wire
Single Pole Distribution Blocks
94270
MFG #: 1421572
Marathon®
29.68000
/ ea
Marathon® Power Splicer/Distribution Block, Series: 142, 600 VAC/VDC, 175 A, 1 Pole, 1 Primary Connections/Pole, 1 Secondary Connection/Pole, 14 to 2/0 AWG Wire, Class J/T/RK1/RK5/G/CC Fuse, 10 kA Short Circuit Current Rating, Black, 2.88 in H x 1.13 in W x 1.78 in D
- Features
| Features: Wire Range: Line Side: (1) 2/0 - 14 AWG; Load Side: (1) 2/0 - 14 AWG; Electrical Ratings: 175 AMP Copper Wire, 135 AMP Aluminum Wire (Based On NEC Table 310-16, 75 ° C Columns); 600 Volts AC/DC (UL 1059 Class C, User Group - General Industrial); Factory And Field Wiring; Mechanical Ratings: Maximum Insulator Base Temperature: 150 ° C (302 ° F) UL RTI; Storage And Transportation Temperature Range: -35 ° C To 110 ° C (-31 ° F To 257 ° F); Flammability Rating Of Insulator Base: UL 94 V-0; Use Outside These Ratings Needs To Be Judged In The End-Use Application; Materials: Connector: High Conductive Aluminum, Tin Plated; Insulator Base: Phenolic; Terminal Set Screws: Aluminum, Tin Plated; Connector Mounting Screw: Steel, Zinc Plated; Agency Approvals: UL Recognized, UL 1059 Terminal Block Standard, File No. XCFR2.E62806; CSA Certified, CSA C22. |
| Flexible stranded wire compliant |
| Multiple wire rating |
| Panel mountable |
| UL94V-0 flammability |
| 125 deg C (257 deg F) UL RTI temperature rating |
| 4 - 13.6 N-m line side torque and load side torque |
| Tin plated connector, terminal set screws and zinc plated connector mounting screws |
| Phenolic insulator, tin plated aluminum connector |
| 2/0 - 14 AWG line, 2/0 - 14 AWG load wire size |
