MIDGET FUSE BLOCK WITH SCREW TERMINAL
Midget Fuse Blocks
73813
MFG #: L60030M-2SQ
Littelfuse®
11.14000
/ ea
The Littelfuse® Class CC, CD and midget blocks offer generous space savings and enhanced value. DIN rail mounting and universal mounting holes are available as well as an indication feature on all Class CD fuse blocks.
- 3D Rendering URL(3D Rendering URL)
- Brochure URL - 11468_ZMLGDEHVFOQAW4NX.pdf(Brochure URL)
- Brochure URL - littelfuse_industrial_distributor_handbook_pf159.pdf(Brochure URL)
- http://www.littelfuse.com(Seller Home Page URL)
- Spec Sheet URL - 11468_5FOPMZU04A1IQRKG.pdf(Spec Sheet URL)
- Spec Sheet URL - littelfuse_fuse_block_cc_cd_midget_datasheet.pdf(Spec Sheet URL)
- Tech Bulletin URL(Tech Bulletin URL)
- Tech Bulletin URL - 11468_80Y1OURLJQBTXWCP.pdf(Tech Bulletin URL)
- Features
DIN Rail Mounting |
Midget fuse blocks are molded of high strength, high temperature material to minimize block breakage during handling and installation, as well as damage due to heat |
Space saving design |
Universal mounting holes for easy replacement |
One hand release from DIN rail optional |
Rejection feature that prevents the insertion of fuses with lower interrupting rating or voltage ratings |
Clip design reduces resistance and heat |
1200 VAC minimum dielectric strength |
Tin plated copper alloy clip/terminals, copper box lug, zinc plated steel pressure plate |
Interlocking fuse blocks allow ganging to produce a fuse block with any number of poles |
Screw with quick connect |
Screw with quick connect |
