Lutron® PHPM-PA-DV-WH Phase Adaptive Power Module, 120 VAC, 16 A, 12 AWG Wire Connection

Lighting Control Power Modules
455715 MFG #: PHPM-PA-DV-WH
Lutron®
490.00000 / ea
Lutron® Power Module, Phase Adaptive, 120 VAC, 16 A, 12 AWG Wire, White, 5.1 in H x 6.3 in W x 1.2 in D
QTY
  • Features
Provides capability for a zone on a GRAFIK Eye control unit (or other product) to dim a fully loaded circuit of lighting. May be used to switch incandescent, electronic low-voltage, magnetic low-voltage, and neon/cold cathode lighting sources, as well as Tu-Wire fluorescent dimming ballasts. Automatically selects leading-edge or trailing-edge dimming for low-voltage transformers. Provides power and dimming for one zone. Up to 3 power modules may be wired on a single GRAFIK Eye zone. Not for use with non-dim loads. Works with 120 VAC versions of GRAFIK Eye QS and GRAFIK Eye 3000 Series control units. LP, LCP, and GP dimming panels, HomeWorks remote power panels, and Lutron 3-wire fluorescent dimmers.
Provides capability for a zone on a GRAFIK Eye® control unit (or other product) to dim a fully loaded circuit of lighting
May be used to control incandescent, electronic low voltage, magnetic low voltage and neon/cold cathode lighting sources, as well as Lutron® Tu-Wire® fluorescent dimming ballasts
Automatically selects leading edge or trailing edge dimming for low voltage transformers
Provides power and dimming for one zone
Up to 3 power modules may be wired on a single GRAFIK Eye® zone
Not for use with non-dim loads
Automatically selects between forward phase/leading edge and reverse phase/trailing edge dimming based on load
Passive infrared motion detection with exclusive Lutron® XCTTM technology for fine motion detection
0 to 40 deg C ambient operating temperature
Relative humidity less than 90% non-condensing, indoor use only
Provides air-gap off
Module protects itself during temporary over current and over voltage conditions
120 to 277 VAC load power
50/60 Hz frequency
