Littelfuse® LFJ60100-1CID POWR-GARD® LFJ Indicating Fuse Block, 600 VAC, 100 A, 6 to 2/0 AWG Wire, 1 Pole
Custom_Product_Images_Illustration
Littelfuse® LFJ60100-1CID POWR-GARD® LFJ Indicating Fuse Block, 600 VAC, 100 A, 6 to 2/0 AWG Wire, 1 Pole
SKU596184
MFGR #LFJ60100-1CID
Your Cost: $70.91/ea
List: The Littelfuse 600 V Class J blocks offer generous space savings and enhanced value over previous generations, such as indication, snap-to-release DIN rail mounting and universal mounting holes.
The Littelfuse 600 V Class J blocks offer generous space savings and enhanced value over previous generations, such as indication, snap-to-release DIN rail mounting and universal mounting holes.
Alternate Catalog Number LFJ601001CID ARRA Compliant N Buy American Compliant N Catalog Number LFJ60100-1CID Connection Type Box Lug Country of Origin CN Currency USD Dimensions 5.44 in L x 1.92 in W x 2.62 in H EU RoHS Indicator Y Fuse Diameter 1 in Fuse Length 4.626 in Gross Weight Per Pack 0.1500 lb Gross Weight per Pack Metric 0.07 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536908585 Material Thermoplastic Mounting Type DIN Rail Number Of Poles 1 Series LFJ Standard UL Listed CSA Certified Standards RoHS CompliantUL ListedCSA CertifiedPROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer Sub Brand LF Series Fuseblock Suitable For Use With JTD_ID, JTD Series Time Delay Fuse and JLS Fast Acting Fuse Temperature Rating 130 °C UNSPSC 39121629 UPC 11 07945818188 UPC 12 079458181883 Stock Status NONSTOCK Brand Littelfuse® Manufacturer Littelfuse Inc. Amperage Rating 100 A Class J Type Class J Fuseblock Voltage Rating 600 VAC Wire Size 6 to 2/0 AWG Space-saving DIN Rail Indication Space saving design up to 45% smaller Universal mounting holes for easy replacement One hand release from DIN rail for ferrule style fuses Reinforced fuse clips are standard on all class J blocks <0.6 ma at 600 V leakage current UL94 V-0 flammability rating Lead (Pb) free Phenolic blocks have side barriers for isolation Indication offered on all versions except 200 to 600A DIN rail releasable for all non-knife blade style fuses Covers available for 100 a and lower to enhance safety
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | LFJ601001CID |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | LFJ60100-1CID |
| Connection Type | Box Lug |
| Country of Origin | CN |
| Currency | USD |
| Dimensions | 5.44 in L x 1.92 in W x 2.62 in H |
| EU RoHS Indicator | Y |
| Fuse Diameter | 1 in |
| Fuse Length | 4.626 in |
| Gross Weight Per Pack | 0.1500 lb |
| Gross Weight per Pack Metric | 0.07 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536908585 |
| Material | Thermoplastic |
| Mounting Type | DIN Rail |
| Number Of Poles | 1 |
| Series | LFJ |
| Standard | UL Listed CSA Certified |
| Standards | RoHS CompliantUL ListedCSA CertifiedPROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer |
| Sub Brand | LF Series Fuseblock |
| Suitable For Use With | JTD_ID, JTD Series Time Delay Fuse and JLS Fast Acting Fuse |
| Temperature Rating | 130 °C |
| UNSPSC | 39121629 |
| UPC 11 | 07945818188 |
| UPC 12 | 079458181883 |
| Stock Status | NONSTOCK |
| Brand | Littelfuse® |
| Manufacturer | Littelfuse Inc. |
| Amperage Rating | 100 A |
| Class | J |
| Type | Class J Fuseblock |
| Voltage Rating | 600 VAC |
| Wire Size | 6 to 2/0 AWG |
| Space-saving DIN Rail Indication |
| Space saving design up to 45% smaller |
| Universal mounting holes for easy replacement |
| One hand release from DIN rail for ferrule style fuses |
| Reinforced fuse clips are standard on all class J blocks |
| <0.6 ma at 600 V leakage current |
| UL94 V-0 flammability rating |
| Lead (Pb) free |
| Phenolic blocks have side barriers for isolation |
| Indication offered on all versions except 200 to 600A |
| DIN rail releasable for all non-knife blade style fuses |
| Covers available for 100 a and lower to enhance safety |
