Littelfuse® L60030C-1PQ POWR-GARD® L600 Fuse Block, 600 VAC/VDC, 30 A, 14 to 10 AWG Wire, 1 Pole
Custom_Product_Images_Illustration
Littelfuse® L60030C-1PQ POWR-GARD® L600 Fuse Block, 600 VAC/VDC, 30 A, 14 to 10 AWG Wire, 1 Pole
SKU9044
MFGR #L60030C-1PQ
Your Cost: $16.05/ea
List: The Littelfuse Class CC, CD and midget blocks offer generous space savings and enhanced value. DIN rail mounting and universal mounting holes are available as well as an indication feature on all Class CD fuse blocks.
The Littelfuse Class CC, CD and midget blocks offer generous space savings and enhanced value. DIN rail mounting and universal mounting holes are available as well as an indication feature on all Class CD fuse blocks.
Alternate Catalog Number L60030C1PQ ARRA Compliant N Buy American Compliant N Catalog Number L60030C-1PQ Connection Type Pressure Plate Country of Origin CN Currency USD Dimensions 3 in L x 0.783 in W x 1.25 in H EU RoHS Indicator Y Fuse Diameter 13/32 in Fuse Length 1-1/2 in Gross Weight Per Pack 0.0880 lb Gross Weight per Pack Metric 40.00 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536904000 Item Group 079458-5R Material Thermoplastic Mounting Type DIN Rail Number Of Poles 1 Series L600C Standard UL Listed CSA Standards RoHS CompliantUL E14721CSA LR7316PROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer Sub Brand L600 Fuseblock Suitable For Use With CCMR, KLDR and KLKR Series Fuse Temperature Rating 125 °C UNSPSC 39121629 UPC 11 07945807007 UPC 12 079458070071 Stock Status NONSTOCK Brand Littelfuse® Manufacturer Littelfuse Inc. Amperage Rating 30 A Class CC Type Class CC Fuseblock Voltage Rating 600 VAC//VDC Wire Size 14 to 10 AWG DIN Rail Mounting 1200 V minimum dielectric strength Space saving design Universal mounting holes for easy replacement Indication offered on CD blocks Rejection feature that prevents the insertion of fuses with lower interrupting rating or voltage ratings Clip design reduces resistance and heat One hand release from DIN rail optional Covers available for all amperages to enhance safety Non DIN rail fuse blocks have interlocking feature allowing ganging for any number of poles Copper box lug Zinc-plated steel screw and captive pressure plate Tin-plated copper alloy clip/terminals Lead (Pb) free 2.3 N-m torque Pressure plate with quick connect terminal Cu solid/stranded wire
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | L60030C1PQ |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | L60030C-1PQ |
| Connection Type | Pressure Plate |
| Country of Origin | CN |
| Currency | USD |
| Dimensions | 3 in L x 0.783 in W x 1.25 in H |
| EU RoHS Indicator | Y |
| Fuse Diameter | 13/32 in |
| Fuse Length | 1-1/2 in |
| Gross Weight Per Pack | 0.0880 lb |
| Gross Weight per Pack Metric | 40.00 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536904000 |
| Item Group | 079458-5R |
| Material | Thermoplastic |
| Mounting Type | DIN Rail |
| Number Of Poles | 1 |
| Series | L600C |
| Standard | UL Listed CSA |
| Standards | RoHS CompliantUL E14721CSA LR7316PROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer |
| Sub Brand | L600 Fuseblock |
| Suitable For Use With | CCMR, KLDR and KLKR Series Fuse |
| Temperature Rating | 125 °C |
| UNSPSC | 39121629 |
| UPC 11 | 07945807007 |
| UPC 12 | 079458070071 |
| Stock Status | NONSTOCK |
| Brand | Littelfuse® |
| Manufacturer | Littelfuse Inc. |
| Amperage Rating | 30 A |
| Class | CC |
| Type | Class CC Fuseblock |
| Voltage Rating | 600 VAC//VDC |
| Wire Size | 14 to 10 AWG |
| DIN Rail Mounting |
| 1200 V minimum dielectric strength |
| Space saving design |
| Universal mounting holes for easy replacement |
| Indication offered on CD blocks |
| Rejection feature that prevents the insertion of fuses with lower interrupting rating or voltage ratings |
| Clip design reduces resistance and heat |
| One hand release from DIN rail optional |
| Covers available for all amperages to enhance safety |
| Non DIN rail fuse blocks have interlocking feature allowing ganging for any number of poles |
| Copper box lug |
| Zinc-plated steel screw and captive pressure plate |
| Tin-plated copper alloy clip/terminals |
| Lead (Pb) free |
| 2.3 N-m torque |
| Pressure plate with quick connect terminal |
| Cu solid/stranded wire |
