Littelfuse®
Littelfuse® GDB61151Z POWR-GARD® GDB Power Distribution Block, 600 VAC/VDC, 115 A, 1 Pole, 8 to 2 AWG/10 to 6 AWG Wire
Custom_Product_Images_Illustration
Littelfuse®
Littelfuse® GDB61151Z POWR-GARD® GDB Power Distribution Block, 600 VAC/VDC, 115 A, 1 Pole, 8 to 2 AWG/10 to 6 AWG Wire
SKU1225262
MFGR #GDB61151Z
Your Cost: $27.59/ea
List: POWR-BLOKSTM Global Distribution Blocks add safety and mounting versatility to our distribution block solutions. The Global Distribution Blocks are approved to UL standards. The Global Distribution Blocks are IP20 finger safe to reduce the risk of contact and eliminate the need for block or panel covers. Installation is quick and easy, all blocks can be mounted on DIN rail or to the panel.
POWR-BLOKSTM Global Distribution Blocks add safety and mounting versatility to our distribution block solutions. The Global Distribution Blocks are approved to UL standards. The Global Distribution Blocks are IP20 finger safe to reduce the risk of contact and eliminate the need for block or panel covers. Installation is quick and easy, all blocks can be mounted on DIN rail or to the panel.
Alternate Catalog Number GDB61151Z ARRA Compliant N Buy American Compliant N Catalog Number GDB61151Z Country of Origin FR Currency USD Dimensions 2.9 in H x 1.06 in W x 1.67 in D EU RoHS Indicator Y Fuse Type Class J Gross Weight Per Pack 0.3200 lb Gross Weight per Pack Metric 0.14 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536908585 Number Of Poles 1 Primary Connections|Pole 2 Secondary Connection|Pole 6 Series GDB Short Circuit Current Rating 100 kA Standard UL LISTED Standards RoHS CompliantCE CertifiedcUL ListedIEC 60947-7-1 RatedUL File No. E309688 Sub Brand GDB Type Touch Safe UNSPSC 39121629 UPC 11 07945896382 UPC 12 079458963823 Stock Status NONSTOCK Brand Littelfuse® Manufacturer Littelfuse Inc. Amperage Rating 115 A Material Thermoplastic Voltage Rating 600 VAC//VDC Wire Size 8 to 2 AWG, 10 to 6 AWG Din Rail or Panel Mount Space saving design Integrated touch-safe cover to increase safety Reliable brass connections for excellent continuity in a smaller design 8 to 2 AWG/10 to 6 AWG brass line, 14 to 4 AWG brass load 31.5 in-lb torque line, 17.5 in-lb torque load Tough safe Global distribution block (2) screw primary, (6) slotted screw secondary 4 mm hex screw line
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
Alternate Catalog Number | GDB61151Z |
ARRA Compliant | N |
Buy American Compliant | N |
Catalog Number | GDB61151Z |
Country of Origin | FR |
Currency | USD |
Dimensions | 2.9 in H x 1.06 in W x 1.67 in D |
EU RoHS Indicator | Y |
Fuse Type | Class J |
Gross Weight Per Pack | 0.3200 lb |
Gross Weight per Pack Metric | 0.14 |
Gross Weight UOM Metric | kg |
Harmonization Tariff Schedule Code | 8536908585 |
Number Of Poles | 1 |
Primary Connections|Pole | 2 |
Secondary Connection|Pole | 6 |
Series | GDB |
Short Circuit Current Rating | 100 kA |
Standard | UL LISTED |
Standards | RoHS CompliantCE CertifiedcUL ListedIEC 60947-7-1 RatedUL File No. E309688 |
Sub Brand | GDB |
Type | Touch Safe |
UNSPSC | 39121629 |
UPC 11 | 07945896382 |
UPC 12 | 079458963823 |
Stock Status | NONSTOCK |
Brand | Littelfuse® |
Manufacturer | Littelfuse Inc. |
Amperage Rating | 115 A |
Material | Thermoplastic |
Voltage Rating | 600 VAC//VDC |
Wire Size | 8 to 2 AWG, 10 to 6 AWG |
Din Rail or Panel Mount |
Space saving design |
Integrated touch-safe cover to increase safety |
Reliable brass connections for excellent continuity in a smaller design |
8 to 2 AWG/10 to 6 AWG brass line, 14 to 4 AWG brass load |
31.5 in-lb torque line, 17.5 in-lb torque load |
Tough safe |
Global distribution block |
(2) screw primary, (6) slotted screw secondary |
4 mm hex screw line |
