Killark® XSX-53 XSX Feed-Through Starting Switch Without Overload Protection, 250/600 VAC, 30/20 A, 10 hp
AC Motor Starting Switches
426348
MFG #: XSX-53
Killark
879.89000
/ ea
Killark® Starting Switch, Feed-Through, Series: XSX, 250/600 VAC, 30/20 A, 10 hp, 3 Poles, NEMA 7/9 Enclosure, Copper Free Aluminum, 6 in H x 3 in W x 4 in D
- Applications
- Features
| Provides manual starting and stopping of small AC or DC motors. Motor running protection when overload heaters are used. XSX Series (without overload protection) is ideally suited for across-the-line applications where a positive disconnect means is required. |
| Enclosures are cast copper-free aluminum alloy. Operating shaft is stainless steel. Ground flange joint between bolted cover and box provide required flame path. Provisions for padlocking switch in either "ON" or "OFF" position is standard. |
| FXSX Series require no external seals (factory sealed) and are NEMA 3 (raintight) rated |
| Enclosures are cast copper-free aluminum alloy |
| Operating shaft is stainless steel |
| Multiple gang assemblies available in combination with pilot lights, pushbuttons and switches on request |
| Ground flange joint between bolted cover and box provide required flame path |
| Provisions for padlocking switch in either on or off position is standard |
| Provides manual starting and stopping of small AC or DC motors |
| 3/4 in hub |
| Class 2510, type K, single gang, 3-phase |
| 2 hp at 115 VAC, 7.5 hp at 200 to 230 VAC, 10 hp at 460 to 575 VAC power rating |
| Without overload protection |
