Hubbell Wiring Device-Kellems Twist-Lock® HBL27W76BK Female Grounding Standard Locking Connector, 480 VAC, 20 A, 3 Poles, 4 Wires, Yellow
Custom_Product_Images_Illustration
Hubbell Wiring Device-Kellems Twist-Lock® HBL27W76BK Female Grounding Standard Locking Connector, 480 VAC, 20 A, 3 Poles, 4 Wires, Yellow
SKU955468
MFGR #HBL27W76BK
Your Cost: $92.29/ea
List: Wiring Device-Kellems Twist-Lock® Locking Connector, Female Grounding Standard, 480 VAC, 20 A, 5 hp, 3 Pole, 4 Wires, NEMA L16-20R, Grade: Industrial, NEMA 4/4X/6/6P/IP65/66/67 Enclosure, 3/8 to 7/8 in Cord Dia, -40 to 60 deg C, Screw Terminal, Thermoplastic Elastomer, Yellow, 2.51 in Dia x 5.69 in L
Wiring Device-Kellems Twist-Lock® Locking Connector, Female Grounding Standard, 480 VAC, 20 A, 5 hp, 3 Pole, 4 Wires, NEMA L16-20R, Grade: Industrial, NEMA 4/4X/6/6P/IP65/66/67 Enclosure, 3/8 to 7/8 in Cord Dia, -40 to 60 deg C, Screw Terminal, Thermoplastic Elastomer, Yellow, 2.51 in Dia x 5.69 in L
Application Power Connection ARRA Compliant C Buy American Compliant C Catalog Number HBL27W76BK Connection Screw Terminals Cord Diameter 3/8 to 7/8 in Country of Origin PR Currency USD Dimensions 2.51 in Dia x 5.69 in L Enclosure NEMA 4/4X/6/6P/IP65/66/67 Environmental Conditions Watertight EU RoHS Indicator C Grade Industrial Gross Weight Per Pack 0.2500 lb Gross Weight per Pack Metric 0.36 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536694020 Height 2.46 in Height [Metric] 6.2484 cm Horsepower 5 hp Length 8.00 in Length [Metric] 20.3200 cm Material Thermoplastic Elastomer Mounting Mounts to Cable NEMA Rating L16-20R Number Of Poles 3 Returnable Y Size 2.51 in x 2.51 in x 5.69 in Standard Meets NEMA WD-1, WD-6 And ANSI Standards Standards ARRA CompliantBuy American Act CompliantRoHS CompliantANSI SpecifiedUL ListedCSA C22.2 No. 42NEMA WD1/WD6 Sub Brand Locking Watertight Devices Temperature Rating -40 to 60 °C Terminal Type Screw Type Connector Body UNSPSC 39121421 UPC 11 78358513182 UPC 12 783585131825 Width 6.50 in Width [Metric] 16.5100 cm Stock Status NONSTOCK Brand Hubbell Wiring Device-Kellems Manufacturer Hubbell Amperage Rating 20 A Color Black Number of Wires 4 Voltage Rating 3 Phase 480 VAC Power Connection Standard Product Smooth body design minimizes collection points simplifying the wash down process Strain relief nut always seals on the body, minimizing debris collection Stainless steel hardware and corrosion-resistant connection points Watertight
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | Power Connection |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | HBL27W76BK |
| Connection | Screw Terminals |
| Cord Diameter | 3/8 to 7/8 in |
| Country of Origin | PR |
| Currency | USD |
| Dimensions | 2.51 in Dia x 5.69 in L |
| Enclosure | NEMA 4/4X/6/6P/IP65/66/67 |
| Environmental Conditions | Watertight |
| EU RoHS Indicator | C |
| Grade | Industrial |
| Gross Weight Per Pack | 0.2500 lb |
| Gross Weight per Pack Metric | 0.36 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536694020 |
| Height | 2.46 in |
| Height [Metric] | 6.2484 cm |
| Horsepower | 5 hp |
| Length | 8.00 in |
| Length [Metric] | 20.3200 cm |
| Material | Thermoplastic Elastomer |
| Mounting | Mounts to Cable |
| NEMA Rating | L16-20R |
| Number Of Poles | 3 |
| Returnable | Y |
| Size | 2.51 in x 2.51 in x 5.69 in |
| Standard | Meets NEMA WD-1, WD-6 And ANSI Standards |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantANSI SpecifiedUL ListedCSA C22.2 No. 42NEMA WD1/WD6 |
| Sub Brand | Locking Watertight Devices |
| Temperature Rating | -40 to 60 °C |
| Terminal Type | Screw |
| Type | Connector Body |
| UNSPSC | 39121421 |
| UPC 11 | 78358513182 |
| UPC 12 | 783585131825 |
| Width | 6.50 in |
| Width [Metric] | 16.5100 cm |
| Stock Status | NONSTOCK |
| Brand | Hubbell Wiring Device-Kellems |
| Manufacturer | Hubbell |
| Amperage Rating | 20 A |
| Color | Black |
| Number of Wires | 4 |
| Voltage Rating | 3 Phase 480 VAC |
| Power Connection |
| Standard Product |
| Smooth body design minimizes collection points simplifying the wash down process |
| Strain relief nut always seals on the body, minimizing debris collection |
| Stainless steel hardware and corrosion-resistant connection points |
| Watertight |
