Hubbell Wiring Device-Kellems HBL® HBL5352BK HBL5352 Compact Duplex Straight Blade Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, Black
Custom_Product_Images_Illustration
Hubbell Wiring Device-Kellems HBL® HBL5352BK HBL5352 Compact Duplex Straight Blade Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, Black
SKU92483
MFGR #HBL5352BK
$/ea
Wiring Device-Kellems HBL® Straight Blade Receptacle, Compact Duplex, Series: HBL5352, 125 VAC, 20 A, 1 hp, 2 Poles, 3 Wires, NEMA 5-20R, Specification Grade, -40 to 75 deg C, Back and Side Wired Terminal, Nylon, Black, 3.28 in H x 1.33 in W x 0.8 in D
Wiring Device-Kellems HBL® Straight Blade Receptacle, Compact Duplex, Series: HBL5352, 125 VAC, 20 A, 1 hp, 2 Poles, 3 Wires, NEMA 5-20R, Specification Grade, -40 to 75 deg C, Back and Side Wired Terminal, Nylon, Black, 3.28 in H x 1.33 in W x 0.8 in D
Application Extra Heavy Duty Compact ARRA Compliant C Buy American Compliant C Catalog Number HBL5352BK Connection Back and Side Wired Screw Terminals Country of Origin US Currency USD Dielectric Strength Withstands 2,000V minimum Dimensions 3.28 in H x 1.33 in W x 0.8 in D Environmental Conditions Indoor Dry unless protected by additional means EU RoHS Indicator Y Grade Specification Gross Weight Per Pack 0.2500 lb Gross Weight per Pack Metric 0.11 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536698000 Height 1.70 in Height [Metric] 4.3180 cm Horsepower 1 hp Length 4.20 in Length [Metric] 10.6680 cm Material Thermoplastic Mounting Screw Mount NEMA Rating 5-20R Number Of Poles 2 Phase 1 Returnable Y Series HBL5352 Size 3.28 in x 1.33 in x 1.05 in Standard Certified to CSA 22.2, No. 42 File 285;Fed. Spec. W-C596G;NEMA® WD-6 Compliant;UL Listed to UL498 File No. E2186 Standards UL 498UL File No. E2186CSA 22.2 No. 42CSA File No. 285Federal Specification WC596NEMA WD-6UL 94 V0 Sub Brand Straight Blade Devices Temperature Rating -40 to 75 °C Terminal Type Back/Side Wired Type Standard Duplex UNSPSC 39121406 UPC 11 78358543500 UPC 12 783585435008 Wattage 2,500 W Width 1.90 in Width [Metric] 4.8260 cm Wire Size #12 AWG to #10 AWG Stock Status NONSTOCK Brand Hubbell Wiring Device-Kellems Manufacturer Hubbell Amperage Rating 20 A Color Black Number of Wires 3 Voltage Rating 125 VAC Extra Heavy Duty Compact Compact design and Self Grounding HBL® extra heavy duty compact receptacles Slender/compact design Triple wipe contacts Nylon face and RTB base Brass contacts, mounting strap and terminal screws, plated brass wire clamp, stainless steel automatic self-grounding clip, steel-zinc plated mounting screws Certified for current interrupting at full rated current Withstands 2000 VAC minimum dielectric voltage 12 to 10 AWG stranded or solid copper wire only Terminals identified in accordance with UL 498 and CSA
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | Extra Heavy Duty Compact |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | HBL5352BK |
| Connection | Back and Side Wired Screw Terminals |
| Country of Origin | US |
| Currency | USD |
| Dielectric Strength | Withstands 2,000V minimum |
| Dimensions | 3.28 in H x 1.33 in W x 0.8 in D |
| Environmental Conditions | Indoor Dry unless protected by additional means |
| EU RoHS Indicator | Y |
| Grade | Specification |
| Gross Weight Per Pack | 0.2500 lb |
| Gross Weight per Pack Metric | 0.11 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536698000 |
| Height | 1.70 in |
| Height [Metric] | 4.3180 cm |
| Horsepower | 1 hp |
| Length | 4.20 in |
| Length [Metric] | 10.6680 cm |
| Material | Thermoplastic |
| Mounting | Screw Mount |
| NEMA Rating | 5-20R |
| Number Of Poles | 2 |
| Phase | 1 |
| Returnable | Y |
| Series | HBL5352 |
| Size | 3.28 in x 1.33 in x 1.05 in |
| Standard | Certified to CSA 22.2, No. 42 File 285;Fed. Spec. W-C596G;NEMA® WD-6 Compliant;UL Listed to UL498 File No. E2186 |
| Standards | UL 498UL File No. E2186CSA 22.2 No. 42CSA File No. 285Federal Specification WC596NEMA WD-6UL 94 V0 |
| Sub Brand | Straight Blade Devices |
| Temperature Rating | -40 to 75 °C |
| Terminal Type | Back/Side Wired |
| Type | Standard Duplex |
| UNSPSC | 39121406 |
| UPC 11 | 78358543500 |
| UPC 12 | 783585435008 |
| Wattage | 2,500 W |
| Width | 1.90 in |
| Width [Metric] | 4.8260 cm |
| Wire Size | #12 AWG to #10 AWG |
| Stock Status | NONSTOCK |
| Brand | Hubbell Wiring Device-Kellems |
| Manufacturer | Hubbell |
| Amperage Rating | 20 A |
| Color | Black |
| Number of Wires | 3 |
| Voltage Rating | 125 VAC |
| Extra Heavy Duty Compact |
| Compact design and Self Grounding |
| HBL® extra heavy duty compact receptacles |
| Slender/compact design |
| Triple wipe contacts |
| Nylon face and RTB base |
| Brass contacts, mounting strap and terminal screws, plated brass wire clamp, stainless steel automatic self-grounding clip, steel-zinc plated mounting screws |
| Certified for current interrupting at full rated current |
| Withstands 2000 VAC minimum dielectric voltage |
| 12 to 10 AWG stranded or solid copper wire only |
| Terminals identified in accordance with UL 498 and CSA |
