Hubbell Wiring Device-Kellems CG816SST STR MALE SS DCG, .875
Custom_Product_Images_Illustration
Hubbell Wiring Device-Kellems CG816SST STR MALE SS DCG, .875
SKU337287
MFGR #CG816SST
Your Cost: $399.52/ea
Deluxe cord grips completely eliminate pull tension on terminals control cable arc-of-bend, prevent cord pull out, and provide a liquidtight seal. They are offered with either aluminum, stainless steel or nylon fittings.
Deluxe cord grips completely eliminate pull tension on terminals control cable arc-of-bend, prevent cord pull out, and provide a liquidtight seal. They are offered with either aluminum, stainless steel or nylon fittings.
Application Straight Male- Form 4 ARRA Compliant C Buy American Compliant C Cable Type Jacketed Catalog Number CG816SST Color Metallic Conductor Range 0.875-1 in (2.22-2.54 mm) Connection Type MNPT Country of Origin PR Currency USD Dimensions 2.02 in Dia x 1.4 in L Environmental Conditions Suitable For Use In Wet Locations When Used With A Listed Sealing Ring Between Box And Fitting. EU RoHS Indicator Y Gross Weight Per Pack 0.6500 lb Gross Weight per Pack Metric 0.32 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 7326200090 Height 2.00 in Height [Metric] 5.0800 cm Length 12.00 in Length [Metric] 30.4800 cm Mounting Locknut or Tapped Opening Number Of Conductors Single Returnable Y Size 1" NPT in Standard UL Listed Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL 898D/899DNECCSA CertifiedUL 94-HBUL94 V-2 Flammability RatingHazardous Location per Class I Div 2, Class II Div 1, 2, Class III Div 1, 2 Sub Brand Kellems Wire Management Temperature Rating Minimum -30 Deg F to 240 Deg F (-34 Deg C to 115 Deg C) °F Type Straight Male Thread UNSPSC 39121431 UPC 11 78358533452 UPC 12 783585334523 Width 2.00 in Width [Metric] 5.0800 cm Stock Status NONSTOCK Brand Hubbell Wiring Device-Kellems Manufacturer Hubbell Cable Openings 7/8 to 1 in Material Stainless Steel Fittings, Stainless Steel Mesh Trade Size 1 in Straight Male- Form 4 Standard Product Specific uses are wiring enclosures, pendant stations, hand tools, construction, processing and material handling equipment, pumps, motors and machine tools Helps to prevent cable pull out Controls cable arc-of-bend Provides a liquidtight seal Corrosion resistant stainless steel mesh with aluminum collar An NPT and PG threaded body allows easy attachment to either threaded hub or knockout in box 1.359 to 1.406 in recommended knockout hole size 0.7 in thread size 1.03 in Dia throat 1.88 in H throat across corner 1.63 in H throat across flat 1-11 1/2 tapered thread
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | Straight Male- Form 4 |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Cable Type | Jacketed |
| Catalog Number | CG816SST |
| Color | Metallic |
| Conductor Range | 0.875-1 in (2.22-2.54 mm) |
| Connection Type | MNPT |
| Country of Origin | PR |
| Currency | USD |
| Dimensions | 2.02 in Dia x 1.4 in L |
| Environmental Conditions | Suitable For Use In Wet Locations When Used With A Listed Sealing Ring Between Box And Fitting. |
| EU RoHS Indicator | Y |
| Gross Weight Per Pack | 0.6500 lb |
| Gross Weight per Pack Metric | 0.32 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 7326200090 |
| Height | 2.00 in |
| Height [Metric] | 5.0800 cm |
| Length | 12.00 in |
| Length [Metric] | 30.4800 cm |
| Mounting | Locknut or Tapped Opening |
| Number Of Conductors | Single |
| Returnable | Y |
| Size | 1" NPT in |
| Standard | UL Listed |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL 898D/899DNECCSA CertifiedUL 94-HBUL94 V-2 Flammability RatingHazardous Location per Class I Div 2, Class II Div 1, 2, Class III Div 1, 2 |
| Sub Brand | Kellems Wire Management |
| Temperature Rating | Minimum -30 Deg F to 240 Deg F (-34 Deg C to 115 Deg C) °F |
| Type | Straight Male Thread |
| UNSPSC | 39121431 |
| UPC 11 | 78358533452 |
| UPC 12 | 783585334523 |
| Width | 2.00 in |
| Width [Metric] | 5.0800 cm |
| Stock Status | NONSTOCK |
| Brand | Hubbell Wiring Device-Kellems |
| Manufacturer | Hubbell |
| Cable Openings | 7/8 to 1 in |
| Material | Stainless Steel Fittings, Stainless Steel Mesh |
| Trade Size | 1 in |
| Straight Male- Form 4 |
| Standard Product |
| Specific uses are wiring enclosures, pendant stations, hand tools, construction, processing and material handling equipment, pumps, motors and machine tools |
| Helps to prevent cable pull out |
| Controls cable arc-of-bend |
| Provides a liquidtight seal |
| Corrosion resistant stainless steel mesh with aluminum collar |
| An NPT and PG threaded body allows easy attachment to either threaded hub or knockout in box |
| 1.359 to 1.406 in recommended knockout hole size |
| 0.7 in thread size |
| 1.03 in Dia throat |
| 1.88 in H throat across corner |
| 1.63 in H throat across flat |
| 1-11 1/2 tapered thread |
