Honeywell BZ-2RW82255-A2-S MICRO SWITCH™ BZ Series Premium Standard Large Basic Switch, 250 VAC, 15 A, Roller Lever Actuator, SPDT
Honeywell BZ-2RW82255-A2-S MICRO SWITCH™ BZ Series Premium Standard Large Basic Switch, 250 VAC, 15 A, Roller Lever Actuator, SPDT
SKUPDW~5303948
MFGR #BZ-2RW82255-A2-S
Price Not Available
MICRO SWITCH™ BZ/BA/BM/BE Series premium, large snap-action switches offer precision operation and sensitive differential travel. These Series meet various international agency requirements, and are often used for precision on/off applications, as well as end of limit, presence/absence, and manual operator interface functions. Configured options with BZ, BA, BM, and BE switches provide a wide variety of operating and interface characteristics. BZ/WZ/YZ switches are 15 A; BA/WA/YA switches are 20 A; BM/WM/YM switches are 22 A; and BE/WE/YE switches are 25 A.
MICRO SWITCH™ BZ/BA/BM/BE Series premium, large snap-action switches offer precision operation and sensitive differential travel. These Series meet various international agency requirements, and are often used for precision on/off applications, as well as end of limit, presence/absence, and manual operator interface functions. Configured options with BZ, BA, BM, and BE switches provide a wide variety of operating and interface characteristics. BZ/WZ/YZ switches are 15 A; BA/WA/YA switches are 20 A; BM/WM/YM switches are 22 A; and BE/WE/YE switches are 25 A.
Action Snap Catalog Number BZ-2RW82255-A2-S Closed Contact Resistance 100000 mOhm Connection Type Threaded Contact Rating 15 A at 250 VAC Country of Origin US Frequency Rating 50/60 Hz Gross Weight Per Pack 0.0700 lb Material Phenolic Number Of Poles 1 Operating Cycles 20000000 Operating Temperature -55 to 85 °C Series BZ Series Size 2 in L x 0.7 in W x 1 in H Standards CE 61058-1, CSA LR41372, UL E12252 Type Premium Standard UPC 11 66119114036 Stock Status NONSTOCK Brand Honeywell Manufacturer Selecta Products Inc. Actuator Lever/Roller Amperage Rating 15 A Contact Configuration SPDT Voltage Rating 250 VAC 1.05 in actuator length 1.67 N maximum operating force 0.42 N minimum release force 0.094 in minimum over travel 0.003 to 0.020 in differential travel 0.139 in size mounting screw 1 in mounting centers 3 in-lb tightening torque General purpose phenolic housing with silver contact material Accepted world wide standard large basic switch Low operating force and differential travel Long mechanical life up to 20000000 cycles at 95% survival Elongated mounting hole for easier, more accurate mounting Bottom facing no 6 screws and cup washers Environment sealed Upto 20000000 mechanical cycles at 95% survival and 100K electrical operations at rated load
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Action | Snap |
| Catalog Number | BZ-2RW82255-A2-S |
| Closed Contact Resistance | 100000 mOhm |
| Connection Type | Threaded |
| Contact Rating | 15 A at 250 VAC |
| Country of Origin | US |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.0700 lb |
| Material | Phenolic |
| Number Of Poles | 1 |
| Operating Cycles | 20000000 |
| Operating Temperature | -55 to 85 °C |
| Series | BZ Series |
| Size | 2 in L x 0.7 in W x 1 in H |
| Standards | CE 61058-1, CSA LR41372, UL E12252 |
| Type | Premium Standard |
| UPC 11 | 66119114036 |
| Stock Status | NONSTOCK |
| Brand | Honeywell |
| Manufacturer | Selecta Products Inc. |
| Actuator | Lever/Roller |
| Amperage Rating | 15 A |
| Contact Configuration | SPDT |
| Voltage Rating | 250 VAC |
| 1.05 in actuator length |
| 1.67 N maximum operating force |
| 0.42 N minimum release force |
| 0.094 in minimum over travel |
| 0.003 to 0.020 in differential travel |
| 0.139 in size mounting screw |
| 1 in mounting centers |
| 3 in-lb tightening torque |
| General purpose phenolic housing with silver contact material |
| Accepted world wide standard large basic switch |
| Low operating force and differential travel |
| Long mechanical life up to 20000000 cycles at 95% survival |
| Elongated mounting hole for easier, more accurate mounting |
| Bottom facing no 6 screws and cup washers |
| Environment sealed |
| Upto 20000000 mechanical cycles at 95% survival and 100K electrical operations at rated load |
