GE
GE 9T51B0187 Type QB Dry Encapsulated General Purpose Transformer, 277 VAC Primary, 120/240 VAC Secondary, 0.25 kVA
Custom_Product_Images_Illustration
GE
GE 9T51B0187 Type QB Dry Encapsulated General Purpose Transformer, 277 VAC Primary, 120/240 VAC Secondary, 0.25 kVA
SKU1028505
MFGR #9T51B0187
$/ea
The complete family of transformers from GE provide quiet, reliable transformer operation. All of the dry type transformers through 1000 kVA are UL listed under the requirements of Standard 506 and 1561. In addition, each transformer meets the requirements of NEMA ST-20, 1992. Type QB, QMS and QMS 3 models are C-UL listed. General-purpose transformers are rated 600 VAC and below for supplying appliance, lighting and power loads from electrical distribution systems. Standard distribution voltages are 600, 480 and 240 VAC, standard load voltages are 480, 240, 208 and 120 VAC. The transformer is used to obtain the load voltage from the distribution voltage. Since no vaults are required for installation, these transformers can be located right at the load to provide the correct voltage for the application. This eliminates the need for long, costly, low voltage feeders.
The complete family of transformers from GE provide quiet, reliable transformer operation. All of the dry type transformers through 1000 kVA are UL listed under the requirements of Standard 506 and 1561. In addition, each transformer meets the requirements of NEMA ST-20, 1992. Type QB, QMS and QMS 3 models are C-UL listed. General-purpose transformers are rated 600 VAC and below for supplying appliance, lighting and power loads from electrical distribution systems. Standard distribution voltages are 600, 480 and 240 VAC, standard load voltages are 480, 240, 208 and 120 VAC. The transformer is used to obtain the load voltage from the distribution voltage. Since no vaults are required for installation, these transformers can be located right at the load to provide the correct voltage for the application. This eliminates the need for long, costly, low voltage feeders.
Catalog Number 9T51B0187 Circuit Type 8175 Frame Connection Type Lead Wire Country of Origin UKN Dimensions 7.38 in H x 6.12 in W x 4.2 in D Enclosure Type NEMA 3R Gross Weight Per Pack 10.0000 lb Housing Material Silicon Steel Insulation IS-12 Mounting Type Wall Number Of Taps 2 Series 9T51B Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL/cUL ListedGSA Compliant Temperature Rating 40 °C Type Type QB Dry Encapsulated UNSPSC 39121027 UPC 11 78317303673 UPC 12 78317303673 Stock Status NONSTOCK Brand GE Manufacturer Industrial Connections & Solutions LLC Frequency Rating 60 Hz Phase 1 Power Rating 0.25 kVA Primary Voltage 277 VAC Secondary Voltage 120/240 VAC These GE transformers feature an encapsulated core and coil in a NEMA 3R non-ventilated weatherproof enclosure.-UL Listed-C-UL Listed-Knockouts provided on back and bottom-High grade silicon steel core-Mounting holes on side for easy access- Wiring compartment includes ground stud Core and coils are contained within a NEMA 3R non-ventilated weatherproof enclosure Copper windings Electro statically unshielded Transformers are built to standard sound level 80 deg C temperature rise K1-factor rated transformer IS-12 insulation system (2) 5% taps below rated primary volts These GE transformers feature an encapsulated core and coil in a NEMA 3R non-ventilated weatherproof enclosure Knockouts provided on back and bottom High grade silicon steel core Mounting holes on side for easy access Wiring compartment includes ground stud 180 deg C insulation temperature
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Catalog Number | 9T51B0187 |
| Circuit Type | 8175 Frame |
| Connection Type | Lead Wire |
| Country of Origin | UKN |
| Dimensions | 7.38 in H x 6.12 in W x 4.2 in D |
| Enclosure Type | NEMA 3R |
| Gross Weight Per Pack | 10.0000 lb |
| Housing Material | Silicon Steel |
| Insulation | IS-12 |
| Mounting Type | Wall |
| Number Of Taps | 2 |
| Series | 9T51B |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL/cUL ListedGSA Compliant |
| Temperature Rating | 40 °C |
| Type | Type QB Dry Encapsulated |
| UNSPSC | 39121027 |
| UPC 11 | 78317303673 |
| UPC 12 | 78317303673 |
| Stock Status | NONSTOCK |
| Brand | GE |
| Manufacturer | Industrial Connections & Solutions LLC |
| Frequency Rating | 60 Hz |
| Phase | 1 |
| Power Rating | 0.25 kVA |
| Primary Voltage | 277 VAC |
| Secondary Voltage | 120/240 VAC |
| These GE transformers feature an encapsulated core and coil in a NEMA 3R non-ventilated weatherproof enclosure.-UL Listed-C-UL Listed-Knockouts provided on back and bottom-High grade silicon steel core-Mounting holes on side for easy access- Wiring compartment includes ground stud |
| Core and coils are contained within a NEMA 3R non-ventilated weatherproof enclosure |
| Copper windings |
| Electro statically unshielded |
| Transformers are built to standard sound level |
| 80 deg C temperature rise |
| K1-factor rated transformer |
| IS-12 insulation system |
| (2) 5% taps below rated primary volts |
| These GE transformers feature an encapsulated core and coil in a NEMA 3R non-ventilated weatherproof enclosure |
| Knockouts provided on back and bottom |
| High grade silicon steel core |
| Mounting holes on side for easy access |
| Wiring compartment includes ground stud |
| 180 deg C insulation temperature |
