Ferraz Shawmut US3J3I UltraSafe™ US3J Finger-Safe Modular Fuse Holder With Blown Fuse Indicator, 600 VAC/VDC, 30 A, 3 Poles
Custom_Product_Images_Illustration
Ferraz Shawmut US3J3I UltraSafe™ US3J Finger-Safe Modular Fuse Holder With Blown Fuse Indicator, 600 VAC/VDC, 30 A, 3 Poles
SKU48225
MFGR #US3J3I
Your Cost: $368.26/ea
Mersen UltraSafe Modular 600 Volt Fuse Holders for Class J fuses introduce a new level of safety and ease for installing or replacing Class J fuses. UltraSafe holders qualify as "finger-safe" to an IP20 grade of protection under IEC standards. The US3J accommodates 30A Class J or 22 x 58 mm French Ferrule fuses. The US6J is for 60A Class J fuses. UltraSafe holders are available in compact 1, 2, or 3-pole units, with or without blown fuse indicators in each pole. Multi-pole units can also be made up in the field by using the multiple-pole Assembly Kits. All units have provisions for locking in the open position for safety during fuse changeouts or equipment servicing. US3J and US6J holders can be snap-mounted to 35 mm DIN-rail and they have a unique latch which will stay open to allow re-positioning of the holder in the future. UltraSafe body material is tough and durable polyamide.
Mersen UltraSafe Modular 600 Volt Fuse Holders for Class J fuses introduce a new level of safety and ease for installing or replacing Class J fuses. UltraSafe holders qualify as "finger-safe" to an IP20 grade of protection under IEC standards. The US3J accommodates 30A Class J or 22 x 58 mm French Ferrule fuses. The US6J is for 60A Class J fuses. UltraSafe holders are available in compact 1, 2, or 3-pole units, with or without blown fuse indicators in each pole. Multi-pole units can also be made up in the field by using the multiple-pole Assembly Kits. All units have provisions for locking in the open position for safety during fuse changeouts or equipment servicing. US3J and US6J holders can be snap-mounted to 35 mm DIN-rail and they have a unique latch which will stay open to allow re-positioning of the holder in the future. UltraSafe body material is tough and durable polyamide.
Alternate Catalog Number US3J3I Application 600V motors, transformers, lighting, heating, control circuits, general loads ARRA Compliant X Buy American Compliant X Catalog Number US3J3I Connection Pressure Plate Connection Type Pressure Plate Country of Origin CN Currency USD Dimensions 114 mm H x 97.5 mm W x 106 mm D EU RoHS Indicator Y Fuse Diameter 22 mm Fuse Length 58 mm Gross Volume Per Pack 54.31 Gross Weight Per Pack 1.4300 lb Gross Weight per Pack Metric 0.65 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536908585 Height 3.15 in Height [Metric] 80.0100 mm Length 4.49 in Length [Metric] 114.0460 mm Material Polyamide Mounting DIN-Rail Mounting Type DIN Rail Number Of Phases 3 Number Of Poles 3 Phase 3 Series US3J Size 4.49 x 3.84 x 3.15 in Standard UL Listed to standard 4248-8, File E52283 CSA Certified C22.2, Class 6225, File 32169 Standards RoHS CompliantUL 4248-8UL File No. E52283CSA C22.2 Class 6225CSA 32169CE Certified Sub Brand UltraSafe?„? Suitable For Use With Class J French Ferrule Fuse UNSPSC 39121624 UPC 11 78200183084 UPC 12 78200183084 Width 3.84 in Width [Metric] 97.5360 mm Stock Status NONSTOCK Brand Ferraz Shawmut Manufacturer Ferraz Shawmut Amperage Rating 30 A Class J Type UltraSafe Voltage Rating 600 VAC Wire Size 14 to 2 AWG 600V motors, transformers, lighting, heating, control circuits, general loads Finger-safe IP20 protection Optional blown fuse indicator lights DIN-rail mount Compact footprint Quick, easy fuse change Finger safe IP20 protection Compact footprint Quick, easy fuse change
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | US3J3I |
| Application | 600V motors, transformers, lighting, heating, control circuits, general loads |
| ARRA Compliant | X |
| Buy American Compliant | X |
| Catalog Number | US3J3I |
| Connection | Pressure Plate |
| Connection Type | Pressure Plate |
| Country of Origin | CN |
| Currency | USD |
| Dimensions | 114 mm H x 97.5 mm W x 106 mm D |
| EU RoHS Indicator | Y |
| Fuse Diameter | 22 mm |
| Fuse Length | 58 mm |
| Gross Volume Per Pack | 54.31 |
| Gross Weight Per Pack | 1.4300 lb |
| Gross Weight per Pack Metric | 0.65 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536908585 |
| Height | 3.15 in |
| Height [Metric] | 80.0100 mm |
| Length | 4.49 in |
| Length [Metric] | 114.0460 mm |
| Material | Polyamide |
| Mounting | DIN-Rail |
| Mounting Type | DIN Rail |
| Number Of Phases | 3 |
| Number Of Poles | 3 |
| Phase | 3 |
| Series | US3J |
| Size | 4.49 x 3.84 x 3.15 in |
| Standard | UL Listed to standard 4248-8, File E52283 CSA Certified C22.2, Class 6225, File 32169 |
| Standards | RoHS CompliantUL 4248-8UL File No. E52283CSA C22.2 Class 6225CSA 32169CE Certified |
| Sub Brand | UltraSafe?„? |
| Suitable For Use With | Class J French Ferrule Fuse |
| UNSPSC | 39121624 |
| UPC 11 | 78200183084 |
| UPC 12 | 78200183084 |
| Width | 3.84 in |
| Width [Metric] | 97.5360 mm |
| Stock Status | NONSTOCK |
| Brand | Ferraz Shawmut |
| Manufacturer | Ferraz Shawmut |
| Amperage Rating | 30 A |
| Class | J |
| Type | UltraSafe |
| Voltage Rating | 600 VAC |
| Wire Size | 14 to 2 AWG |
| 600V motors, transformers, lighting, heating, control circuits, general loads |
| Finger-safe IP20 protection Optional blown fuse indicator lights DIN-rail mount Compact footprint Quick, easy fuse change |
| Finger safe IP20 protection |
| Compact footprint |
| Quick, easy fuse change |
