Bussmann
Edison S-8202-1 8000 Non-Indicating Fuse Block, 300 VAC/VDC, 1.25 A, 1 Pole
Custom_Product_Images_Illustration
Bussmann
Edison S-8202-1 8000 Non-Indicating Fuse Block, 300 VAC/VDC, 1.25 A, 1 Pole
SKU57352
MFGR #S-8202-1
Your Cost: $5.4836/ea($548.36 / c)
List: Edison Fuse Block, Non-Indicating, Series: 8000, 300 VAC/VDC, 1.25 A, 1 Pole, 1/4 in Quick-Connect, Bolt Mount, 1-1/4 in Fuse Length, 1/4 in Fuse Dia, 130 deg C, Thermoplastic, 2 in L x 0.5 in W x 0.56 in H
Edison Fuse Block, Non-Indicating, Series: 8000, 300 VAC/VDC, 1.25 A, 1 Pole, 1/4 in Quick-Connect, Bolt Mount, 1-1/4 in Fuse Length, 1/4 in Fuse Dia, 130 deg C, Thermoplastic, 2 in L x 0.5 in W x 0.56 in H
ARRA Compliant C Buy American Compliant C Catalog Number S-8202-1 Connection 1/4 IN Quick Connect Connection Type Quick-Connect Country of Origin US Currency USD Dimensions 2 in L x 0.5 in W x 0.56 in H EU RoHS Indicator C Fuse Diameter 1/4 in Fuse Length 1-1/4 in Gross Weight Per Pack 0.0200 lb Gross Weight per Pack Metric 0.01 Gross Weight UOM Metric kg Height 0.62 in Height [Metric] 15.8750 mm Length 2.38 in Length [Metric] 6.0325 cm Material Bronze/Tin/Thermoplastic Mounting Bolt-In Mounting Type Bolt-In Number Of Poles 1 Operating Temperature 130 Deg C Series 8200 Size 2.00 In Length X 0.50 In Width X 0.56 In Height Standard UL, CSA, CE Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL File No. E14853 Guide No. IZLT2CE CertifiedCSA 6225-01 File No. 47235 Temperature Rating 130 °C UNSPSC 39121624 UPC 11 05171211759 UPC 12 051712117593 Width 0.50 in Width [Metric] 12.7000 mm Stock Status NONSTOCK Brand Bussmann Manufacturer Eaton Amperage Rating 16/20 A Type Breakaway Voltage Rating 300 VAC//VDC For Use With 1/4 In X 1-1/4 In Fuse 40 deg, 1/4 in quick connect terminal Thermoplastic body, bright tin plated spring bronze clip 20 A UL and 16 A CSA rated Anti-rotational pin Flame retardant thermoplastic construction 25 A UL and 21 A CSA maximum current rating bolt-in and snap-in mounting available All types of terminal configurations 130 deg C Bolt-In and 110 deg C Snap-In temperature rating 1/4 in Quick connect terminal
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | S-8202-1 |
| Connection | 1/4 IN Quick Connect |
| Connection Type | Quick-Connect |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 2 in L x 0.5 in W x 0.56 in H |
| EU RoHS Indicator | C |
| Fuse Diameter | 1/4 in |
| Fuse Length | 1-1/4 in |
| Gross Weight Per Pack | 0.0200 lb |
| Gross Weight per Pack Metric | 0.01 |
| Gross Weight UOM Metric | kg |
| Height | 0.62 in |
| Height [Metric] | 15.8750 mm |
| Length | 2.38 in |
| Length [Metric] | 6.0325 cm |
| Material | Bronze/Tin/Thermoplastic |
| Mounting | Bolt-In |
| Mounting Type | Bolt-In |
| Number Of Poles | 1 |
| Operating Temperature | 130 Deg C |
| Series | 8200 |
| Size | 2.00 In Length X 0.50 In Width X 0.56 In Height |
| Standard | UL, CSA, CE |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL File No. E14853 Guide No. IZLT2CE CertifiedCSA 6225-01 File No. 47235 |
| Temperature Rating | 130 °C |
| UNSPSC | 39121624 |
| UPC 11 | 05171211759 |
| UPC 12 | 051712117593 |
| Width | 0.50 in |
| Width [Metric] | 12.7000 mm |
| Stock Status | NONSTOCK |
| Brand | Bussmann |
| Manufacturer | Eaton |
| Amperage Rating | 16/20 A |
| Type | Breakaway |
| Voltage Rating | 300 VAC//VDC |
| For Use With 1/4 In X 1-1/4 In Fuse |
| 40 deg, 1/4 in quick connect terminal |
| Thermoplastic body, bright tin plated spring bronze clip |
| 20 A UL and 16 A CSA rated |
| Anti-rotational pin |
| Flame retardant thermoplastic construction |
| 25 A UL and 21 A CSA maximum current rating |
| bolt-in and snap-in mounting available |
| All types of terminal configurations |
| 130 deg C Bolt-In and 110 deg C Snap-In temperature rating |
| 1/4 in Quick connect terminal |
