Dongan 35-M025 35 Series Dry General Purpose Ventilated Isolation Transformer, 120/240 VAC Primary, 12/24 VAC Secondary, 0.5 kVA
Custom_Product_Images_Illustration
Dongan 35-M025 35 Series Dry General Purpose Ventilated Isolation Transformer, 120/240 VAC Primary, 12/24 VAC Secondary, 0.5 kVA
SKUPDW~555110
MFGR #35-M025
Price Not Available
Dongan Isolation Transformer, Dry General Purpose Ventilated, Series: 35 Series, 120/240 VAC Primary, 12/24 VAC Secondary, 0.5 kVA, 50/60 Hz, 1 Phase, 4.1/2 A Maximum, Lead Wire, Wall Mount, 100% Duty Cycle, 105 deg C, NEMA 3R, 55 deg C, 9.28 in H x 5.5 in W x 4.75 in D
Dongan Isolation Transformer, Dry General Purpose Ventilated, Series: 35 Series, 120/240 VAC Primary, 12/24 VAC Secondary, 0.5 kVA, 50/60 Hz, 1 Phase, 4.1/2 A Maximum, Lead Wire, Wall Mount, 100% Duty Cycle, 105 deg C, NEMA 3R, 55 deg C, 9.28 in H x 5.5 in W x 4.75 in D
Catalog Number 35-M025 Connection Type Lead Wire Country of Origin USA Dimensions 9.28 in H x 5.5 in W x 4.75 in D Enclosure Type NEMA 3R Gross Weight Per Pack 19.0000 lb Insulation 105 Maximum Amperage Rating 4.1/2 A Mounting Type Wall Series 35 Series Standards UL File No. E3210CSA File No. LR 560RoHS Compliant Temperature Rating 55 °C Type Dry General Purpose Ventilated UNSPSC 39121029 UPC 11 78249035826 Stock Status NONSTOCK Brand Dongan Manufacturer Dongan Electric Frequency Rating 50/60 Hz Phase 1 Power Rating 0.5 kVA Primary Voltage 120/240 VAC Secondary Voltage 12/24 VAC Features: UL Listed, File E3210, CSA Certified, File LR 560; Copper Windings And Copper Lead Wire Terminations Used Throughout; Series 35 Has A UL Class 105 ° C Insulation System With 55 ° C Temperature Rise At A Maximum Ambient Of 40 ° C; This Insures A Long Life And Cool Operating Temperatures; NEMA-3R, Wall Mount Enclosure Suitable For Indoor Or Outdoor Use; May Be Used In Banks Of 2 Or 3 Units For Standard Three Phase Voltages And Nonstandard, Open Delta Auto-Transformer Applications; Multiple Knockouts Provide Convenient Conduit Entry And Exit Locations Through The Front Access Wiring Compartment; Ground Studs Provided For Bonding Compatibility With Both Metallic And Nonmetallic Conduit; Nonstandard Designs Are Available By Consulting The Factory Or Your Dongan Representative; Double Wound, Isolation Type Transformers; Temperature Rise: 55 ° C Temper Copper windings and copper lead wire terminations used throughout Series 35 has a UL class 105 deg C insulation system with 55 deg C temperature rise at a maximum ambient of 40 deg C This insures a long life and cool operating temperatures May be used in banks of 2 or 3 units for standard three phase voltages and nonstandard, open delta autotransformer applications Multiple knockouts provide convenient conduit entry and exit locations through the front access wiring compartment Ground studs provided for bonding compatibility with both metallic and nonmetallic conduit Nonstandard designs are available by consulting the factory or your dongan representative Double wound Type M 4.1/2 A (primary), 41.6/20.8 A (secondary)
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Catalog Number | 35-M025 |
| Connection Type | Lead Wire |
| Country of Origin | USA |
| Dimensions | 9.28 in H x 5.5 in W x 4.75 in D |
| Enclosure Type | NEMA 3R |
| Gross Weight Per Pack | 19.0000 lb |
| Insulation | 105 |
| Maximum Amperage Rating | 4.1/2 A |
| Mounting Type | Wall |
| Series | 35 Series |
| Standards | UL File No. E3210CSA File No. LR 560RoHS Compliant |
| Temperature Rating | 55 °C |
| Type | Dry General Purpose Ventilated |
| UNSPSC | 39121029 |
| UPC 11 | 78249035826 |
| Stock Status | NONSTOCK |
| Brand | Dongan |
| Manufacturer | Dongan Electric |
| Frequency Rating | 50/60 Hz |
| Phase | 1 |
| Power Rating | 0.5 kVA |
| Primary Voltage | 120/240 VAC |
| Secondary Voltage | 12/24 VAC |
| Features: UL Listed, File E3210, CSA Certified, File LR 560; Copper Windings And Copper Lead Wire Terminations Used Throughout; Series 35 Has A UL Class 105 ° C Insulation System With 55 ° C Temperature Rise At A Maximum Ambient Of 40 ° C; This Insures A Long Life And Cool Operating Temperatures; NEMA-3R, Wall Mount Enclosure Suitable For Indoor Or Outdoor Use; May Be Used In Banks Of 2 Or 3 Units For Standard Three Phase Voltages And Nonstandard, Open Delta Auto-Transformer Applications; Multiple Knockouts Provide Convenient Conduit Entry And Exit Locations Through The Front Access Wiring Compartment; Ground Studs Provided For Bonding Compatibility With Both Metallic And Nonmetallic Conduit; Nonstandard Designs Are Available By Consulting The Factory Or Your Dongan Representative; Double Wound, Isolation Type Transformers; Temperature Rise: 55 ° C Temper |
| Copper windings and copper lead wire terminations used throughout |
| Series 35 has a UL class 105 deg C insulation system with 55 deg C temperature rise at a maximum ambient of 40 deg C |
| This insures a long life and cool operating temperatures |
| May be used in banks of 2 or 3 units for standard three phase voltages and nonstandard, open delta autotransformer applications |
| Multiple knockouts provide convenient conduit entry and exit locations through the front access wiring compartment |
| Ground studs provided for bonding compatibility with both metallic and nonmetallic conduit |
| Nonstandard designs are available by consulting the factory or your dongan representative |
| Double wound |
| Type M |
| 4.1/2 A (primary), 41.6/20.8 A (secondary) |
