Color-Keyed® 54101 Thomas & Betts #14 TO #10 CU STD. BAR. 1/4 BOLT
Custom_Product_Images_Illustration
Color-Keyed® 54101 Thomas & Betts #14 TO #10 CU STD. BAR. 1/4 BOLT
SKU485797
MFGR #54101
Your Cost: $11.1606/ea($1,116.06 / c)
The Color-Keyed® compression system ensures a proper crimp onto the conductor by matching the right connector to the right tool and die, using a color coding system that was developed and introduced to the industry by Thomas & Betts. When using the Color-Keyed® compression system with our Blackburn® line of compression connectors, the installer can count on a reliable, high quality connection.
The Color-Keyed® compression system ensures a proper crimp onto the conductor by matching the right connector to the right tool and die, using a color coding system that was developed and introduced to the industry by Thomas & Betts. When using the Color-Keyed® compression system with our Blackburn® line of compression connectors, the installer can count on a reliable, high quality connection.
Alternate Catalog Number 7TAH007100R0001 ARRA Compliant C Barrel Size 0.2 in Dia Barrel Type Standard Buy American Compliant C Cable Size 14-10 AWG Catalog Number 54101 Color Yellow Country of Origin MX Currency USD EU RoHS Indicator C Gross Volume Per Pack 0.01 Gross Volume per Pack Metric 0.00 Gross Weight Per Pack 0.0100 lb Gross Weight per Pack Metric 0.00 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536904000 Height 2.25 in Height [Metric] 5.7150 cm Insulation None Item Group 1L Item Group 2 1LA Length 3.25 in Length [Metric] 8.2550 cm Mounting Hole Size 0.281 in Number Of Holes 1 Overall Length 1.23 in Returnable A Series 54100 Standard UL E9809 Standards UL Listed, CSA Certified, RoHS Compliant Sub Brand Color Keyed Tongue Size 0.56 in L x 0.5 in W x 0.05 in THK Tongue Type Straight Type 1-Hole UNSPSC 39121405 UPC 11 78621095399 UPC 12 786210953991 Voltage Rating 35 kVA Width 2.75 in Width [Metric] 6.9850 cm Stock Status NONSTOCK Brand Color-Keyed® Manufacturer Thomas & Betts Conductor Size 14 to 10 AWG Conductor Type Copper Die Code ERG2002 Material Copper Stud Size 1/4 in Peep hole High conductivity wrought copper
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | 7TAH007100R0001 |
| ARRA Compliant | C |
| Barrel Size | 0.2 in Dia |
| Barrel Type | Standard |
| Buy American Compliant | C |
| Cable Size | 14-10 AWG |
| Catalog Number | 54101 |
| Color | Yellow |
| Country of Origin | MX |
| Currency | USD |
| EU RoHS Indicator | C |
| Gross Volume Per Pack | 0.01 |
| Gross Volume per Pack Metric | 0.00 |
| Gross Weight Per Pack | 0.0100 lb |
| Gross Weight per Pack Metric | 0.00 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536904000 |
| Height | 2.25 in |
| Height [Metric] | 5.7150 cm |
| Insulation | None |
| Item Group | 1L |
| Item Group 2 | 1LA |
| Length | 3.25 in |
| Length [Metric] | 8.2550 cm |
| Mounting Hole Size | 0.281 in |
| Number Of Holes | 1 |
| Overall Length | 1.23 in |
| Returnable | A |
| Series | 54100 |
| Standard | UL E9809 |
| Standards | UL Listed, CSA Certified, RoHS Compliant |
| Sub Brand | Color Keyed |
| Tongue Size | 0.56 in L x 0.5 in W x 0.05 in THK |
| Tongue Type | Straight |
| Type | 1-Hole |
| UNSPSC | 39121405 |
| UPC 11 | 78621095399 |
| UPC 12 | 786210953991 |
| Voltage Rating | 35 kVA |
| Width | 2.75 in |
| Width [Metric] | 6.9850 cm |
| Stock Status | NONSTOCK |
| Brand | Color-Keyed® |
| Manufacturer | Thomas & Betts |
| Conductor Size | 14 to 10 AWG |
| Conductor Type | Copper |
| Die Code | ERG2002 |
| Material | Copper |
| Stud Size | 1/4 in |
| Peep hole |
| High conductivity wrought copper |
