Bussmann® S-8201-1 S-8000 Fuse Block, 300 VAC/VDC, 1 Pole

Name: Bussmann® S-8201-1 S-8000 Fuse Block, 300 VAC/VDC, 1 Pole
Brand: Bussmann
SKU: PDW~252046

Custom_Product_Images_Illustration

SKU177951

MFGR #S-8201-1

$/ea

The minimum package quantity is 10

Bussmann Fuse Block, Series: S-8000, 300 VAC/VDC, 1 Pole, 1/4 in Quick-Connect, 1-1/4 in Fuse Length, Thermoplastic

: ARRA Compliant
C
Buy American Compliant
C
Catalog Number
S-8201-1
Connection
1/4 IN Quick Connect
Connection Type
1/4 in Quick-Connect
Country of Origin
US
Currency
USD
Dimensions
2.16 in L x 0.5 in W x 0.56 in H
EU RoHS Indicator
C
Fuse Diameter
1/4
Fuse Length
1-1/4
Gross Weight Per Pack
0.0200 lb
Gross Weight per Pack Metric
0.77
Gross Weight UOM Metric
kg
Height
5.40 in
Height [Metric]
13.7160 cm
Length
2.40 in
Length [Metric]
6.0960 cm
Material
Thermoplastic
Mounting
Bolt-In
Mounting Type
Bolt-In/Tight Cluster
Number Of Poles
1
Operating Temperature
130 Deg C
Series
S-8200
Size
2.16 In Length X 0.50 In Width X 0.56 In Height
Standard
UL, CSA, CE
Standards
ARRA CompliantBAA CompliantCE CertifiedCSA Class 6225-01, File 47235RoHS CompliantUL File E14853, Guide IZLT2UL 94V0
Suitable For Use With
1/4 x 1-1/4 in Fuses
Temperature Rating
130 °C
UNSPSC
39121624
UPC 11
05171211727
UPC 12
051712117272
Width
2.90 in
Width [Metric]
7.3660 cm
Stock Status
NONSTOCK
Brand
Bussmann
Manufacturer
COOPER BUSSMANN
Amperage Rating
16/20 A
Type
Breakaway
Voltage Rating
300 VAC//VDC
: Catalog
Seller Home Page
Spec Sheet 2
Spec Sheet
: For Used With 1/4 In X 1-1/4 In Fuse
Clips made of bright tin-plated spring-bronze
Anti-rotational pin provided
Flame retardant thermoplastic meets UL 94V0
30 A UL/16 A CSA fuse block
Straight terminal angle fuse block
Straight termina

ARRA Compliant	C
Buy American Compliant	C
Catalog Number	S-8201-1
Connection	1/4 IN Quick Connect
Connection Type	1/4 in Quick-Connect
Country of Origin	US
Currency	USD
Dimensions	2.16 in L x 0.5 in W x 0.56 in H
EU RoHS Indicator	C
Fuse Diameter	1/4
Fuse Length	1-1/4
Gross Weight Per Pack	0.0200 lb
Gross Weight per Pack Metric	0.77
Gross Weight UOM Metric	kg
Height	5.40 in
Height [Metric]	13.7160 cm
Length	2.40 in
Length [Metric]	6.0960 cm
Material	Thermoplastic
Mounting	Bolt-In
Mounting Type	Bolt-In/Tight Cluster
Number Of Poles	1
Operating Temperature	130 Deg C
Series	S-8200
Size	2.16 In Length X 0.50 In Width X 0.56 In Height
Standard	UL, CSA, CE
Standards	ARRA CompliantBAA CompliantCE CertifiedCSA Class 6225-01, File 47235RoHS CompliantUL File E14853, Guide IZLT2UL 94V0
Suitable For Use With	1/4 x 1-1/4 in Fuses
Temperature Rating	130 °C
UNSPSC	39121624
UPC 11	05171211727
UPC 12	051712117272
Width	2.90 in
Width [Metric]	7.3660 cm
Stock Status	NONSTOCK
Brand	Bussmann
Manufacturer	COOPER BUSSMANN
Amperage Rating	16/20 A
Type	Breakaway
Voltage Rating	300 VAC//VDC
