Bussmann
Bussmann® PC-Tron PCC-2-R Subminiature Fast Acting Fuse, 2 A, 250 VAC/450 VDC, 50 A Interrupt, Leaded Body
Custom_Product_Images_Illustration
Bussmann
Bussmann® PC-Tron PCC-2-R Subminiature Fast Acting Fuse, 2 A, 250 VAC/450 VDC, 50 A Interrupt, Leaded Body
SKU855463
MFGR #PCC-2-R
Your Cost: $5.16/ea
List: Bussmann PC-Tron Fast Acting Fuse, Subminiature, Indicating/Non-Indicating: Non-Indicating, 2 A, 250 VAC/450 VDC, 50 A Interrupt, 4 hr at 100% Response, Radial Terminal, Leaded Body, 1 Element, 0.29 in H x 0.3 in W x 0.095 in D Body Size
Bussmann PC-Tron Fast Acting Fuse, Subminiature, Indicating/Non-Indicating: Non-Indicating, 2 A, 250 VAC/450 VDC, 50 A Interrupt, 4 hr at 100% Response, Radial Terminal, Leaded Body, 1 Element, 0.29 in H x 0.3 in W x 0.095 in D Body Size
Alternate Catalog Number PCC-2-R Application Aviation ARRA Compliant C Buy American Compliant C Catalog Number PCC-2-R Country of Origin MUL Currency USD EU RoHS Indicator C Gross Weight Per Pack 0.0100 lb Gross Weight per Pack Metric 0.01 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536100040 Height 0.32 in Height [Metric] 0.8128 cm Length 0.35 in Length [Metric] 0.8890 cm Material Board washable Response Time 4 hr at 100%, 10 sec at 200% s Size 0.300 In Width X 0.095 In Depth X 0.290 In Height Standard CSA ,UL,RoHS Compliant Standards UL File No. E19180, CSA 42731, RoHS Compliant Sub Brand Bussmann Series Type Fast-acting fuse Type Of Indicators Non-Indicating UNSPSC 39121611 UPC 11 05171250379 UPC 12 051712503792 Width 0.18 in Width [Metric] 0.4674 cm Stock Status NONSTOCK Brand Bussmann Manufacturer Eaton Amperage Rating 2 A Interrupt Rating 50 AIC at 250 Vac4.4 kAIC at 350 Vdc10 kAIC at 125 Vac Voltage Rating 250//450 VAC//VDC Aviation Radial leaded Radial leaded, fast-acting thru-hole fuse Board washable Short, 0.1 in (straight) lead length The PC-Tron subminiature fuse is UL Recognized for DC supplementary over current protection to provide individual protection for components or internal circuits in equipment Suitability for a specific application is dependent on time constants and capacitance values It is the responsibility of the customer to evaluate the information provided for applicability to their particular application 50 A at 250 VAC, 10 kA at 125 VAC and 300 A minimum, 5900 A Maximum at 450 VDC interrupt rating 4 hr minimum at 1 10 sec maximum at 200% response time
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | PCC-2-R |
| Application | Aviation |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | PCC-2-R |
| Country of Origin | MUL |
| Currency | USD |
| EU RoHS Indicator | C |
| Gross Weight Per Pack | 0.0100 lb |
| Gross Weight per Pack Metric | 0.01 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536100040 |
| Height | 0.32 in |
| Height [Metric] | 0.8128 cm |
| Length | 0.35 in |
| Length [Metric] | 0.8890 cm |
| Material | Board washable |
| Response Time | 4 hr at 100%, 10 sec at 200% s |
| Size | 0.300 In Width X 0.095 In Depth X 0.290 In Height |
| Standard | CSA ,UL,RoHS Compliant |
| Standards | UL File No. E19180, CSA 42731, RoHS Compliant |
| Sub Brand | Bussmann Series |
| Type | Fast-acting fuse |
| Type Of Indicators | Non-Indicating |
| UNSPSC | 39121611 |
| UPC 11 | 05171250379 |
| UPC 12 | 051712503792 |
| Width | 0.18 in |
| Width [Metric] | 0.4674 cm |
| Stock Status | NONSTOCK |
| Brand | Bussmann |
| Manufacturer | Eaton |
| Amperage Rating | 2 A |
| Interrupt Rating | 50 AIC at 250 Vac4.4 kAIC at 350 Vdc10 kAIC at 125 Vac |
| Voltage Rating | 250//450 VAC//VDC |
| Aviation |
| Radial leaded |
| Radial leaded, fast-acting thru-hole fuse |
| Board washable |
| Short, 0.1 in (straight) lead length |
| The PC-Tron subminiature fuse is UL Recognized for DC supplementary over current protection to provide individual protection for components or internal circuits in equipment |
| Suitability for a specific application is dependent on time constants and capacitance values |
| It is the responsibility of the customer to evaluate the information provided for applicability to their particular application |
| 50 A at 250 VAC, 10 kA at 125 VAC and 300 A minimum, 5900 A Maximum at 450 VDC interrupt rating |
| 4 hr minimum at 1 10 sec maximum at 200% response time |
