Burndy® YA29LB HYLUG™ YA-LB 1-Hole Compression Lug With Inspection Window, 250 kcmil Stranded Solid Copper Conductor
Custom_Product_Images_Illustration
Burndy® YA29LB HYLUG™ YA-LB 1-Hole Compression Lug With Inspection Window, 250 kcmil Stranded Solid Copper Conductor
SKU85933
MFGR #YA29LB
Your Cost: $11.93/ea
List: BURNDY® HYLUG™ terminals, redesigned for terminating copper conductors in a wide variety of electrical connections, including heavy-duty industrial, utility, commercial, and telecommunications applications. The HYLUG™ terminals require simple cable preparation for an easily installed permanent and inspectable cable termination. The terminals are listed by UL (UL STD. 486A) and CSA certified to 600 volts, when applied with the proper tool and die combination. The terminals may be used in applications to 35 KV.
BURNDY® HYLUG™ terminals, redesigned for terminating copper conductors in a wide variety of electrical connections, including heavy-duty industrial, utility, commercial, and telecommunications applications. The HYLUG™ terminals require simple cable preparation for an easily installed permanent and inspectable cable termination. The terminals are listed by UL (UL STD. 486A) and CSA certified to 600 volts, when applied with the proper tool and die combination. The terminals may be used in applications to 35 KV.
Application Wire Termination ARRA Compliant C Barrel Size 0.75 in OD x 1.04 in L Barrel Type Belled End/Standard/Short Buy American Compliant C Catalog Number YA29LB Color Yellow Color Code Yellow Country of Origin US EU RoHS Indicator Y Gross Weight Per Pack 0.1400 lb Gross Weight per Pack Metric 0.06 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8535908020 Height 0.75 in Height [Metric] 1.9050 cm Length 2.77 in Length [Metric] 7.0358 cm Overall Length 2.77 in Returnable Y Series YA-LB Specifications 1-1/16 in L Wire Strip Standard UL 486A-486B Sub Brand HYLUG Temperature Rating 90 °C Tongue Size 1.11 in W x 0.16 in THK Tongue Type Standard Straight Type Standard Belled Barrel, Tin Plated UNSPSC 39121405 UPC 11 78181050442 UPC 12 781810504420 Voltage Rating 35,000 V Width 1.11 in Width [Metric] 2.8194 cm Stock Status NONSTOCK Brand BURNDY® Manufacturer BURNDY® Conductor Size 4/0 AWG Conductor Type Solid/Stranded Copper Die Code 16 Material Copper Stud Size 1/2 in Wire Termination Features: UL Listed 90 DEG C, 600 V - 35 KV, Temperature Rating: 90 DEG C, Tools, Die Nest Catalog Number, Die Indentor Catalog Number: U29D-1 Die Nest, Y34PR2 Die Indentor, Finish: Electro-Tin Plated, Conductor Type: Flexible Copper, Dieless Tools (number Of Crimps): Y81KFT, Y81KFTMBH, PAT81KFT-18V Tool, (1), Die Index: 1023, Wire Strip Length: 1-1/16 IN 4/0 Flex (Class H, I, G, M), 4/0 (550/NO 24) DLO, 250 (61) navy cable conductor size Standard barre
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | Wire Termination |
| ARRA Compliant | C |
| Barrel Size | 0.75 in OD x 1.04 in L |
| Barrel Type | Belled End/Standard/Short |
| Buy American Compliant | C |
| Catalog Number | YA29LB |
| Color | Yellow |
| Color Code | Yellow |
| Country of Origin | US |
| EU RoHS Indicator | Y |
| Gross Weight Per Pack | 0.1400 lb |
| Gross Weight per Pack Metric | 0.06 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8535908020 |
| Height | 0.75 in |
| Height [Metric] | 1.9050 cm |
| Length | 2.77 in |
| Length [Metric] | 7.0358 cm |
| Overall Length | 2.77 in |
| Returnable | Y |
| Series | YA-LB |
| Specifications | 1-1/16 in L Wire Strip |
| Standard | UL 486A-486B |
| Sub Brand | HYLUG |
| Temperature Rating | 90 °C |
| Tongue Size | 1.11 in W x 0.16 in THK |
| Tongue Type | Standard Straight |
| Type | Standard Belled Barrel, Tin Plated |
| UNSPSC | 39121405 |
| UPC 11 | 78181050442 |
| UPC 12 | 781810504420 |
| Voltage Rating | 35,000 V |
| Width | 1.11 in |
| Width [Metric] | 2.8194 cm |
| Stock Status | NONSTOCK |
| Brand | BURNDY® |
| Manufacturer | BURNDY® |
| Conductor Size | 4/0 AWG |
| Conductor Type | Solid/Stranded Copper |
| Die Code | 16 |
| Material | Copper |
| Stud Size | 1/2 in |
| Wire Termination |
| Features: UL Listed 90 DEG C, 600 V - 35 KV, Temperature Rating: 90 DEG C, Tools, Die Nest Catalog Number, Die Indentor Catalog Number: U29D-1 Die Nest, Y34PR2 Die Indentor, Finish: Electro-Tin Plated, Conductor Type: Flexible Copper, Dieless Tools (number Of Crimps): Y81KFT, Y81KFTMBH, PAT81KFT-18V Tool, (1), Die Index: 1023, Wire Strip Length: 1-1/16 IN |
| 4/0 Flex (Class H, I, G, M), 4/0 (550/NO 24) DLO, 250 (61) navy cable conductor size |
| Standard barre |
