Burndy® YA252LN HYLUG™ YA-2LN 2-Hole Compression Lug With Inspection Window, 1/0 AWG Copper Conductor, 1/2 in Stud, 12, Copper
Custom_Product_Images_Illustration
Burndy® YA252LN HYLUG™ YA-2LN 2-Hole Compression Lug With Inspection Window, 1/0 AWG Copper Conductor, 1/2 in Stud, 12, Copper
SKU19521
MFGR #YA252LN
Your Cost: $14.44/ea
List: BURNDY's compression connectors are designed for reliable and controllable electrical connections. The complete installation is fully inspectable. They are high conductivity copper and operate cooler than the wire on which they are installed. The connectors withstand a wide range of electrical and environmental conditions, including current surges, temperatures, corrosion and vibrations, for a wide variety of applications. These features mean a consistently high quality connection at a low installed cost. Copper compression connectors are manufactured from high-conductivity electrolytic copper. The connectors are normally tinplated, lead-plated, or plated with proprietary BURNDY® brite finish to provide durable long-lasting corrosion resistance. The connector design has been matched to the cable size to provide the necessary physical strength requirements for reliable electrical performance.
BURNDY's compression connectors are designed for reliable and controllable electrical connections. The complete installation is fully inspectable. They are high conductivity copper and operate cooler than the wire on which they are installed. The connectors withstand a wide range of electrical and environmental conditions, including current surges, temperatures, corrosion and vibrations, for a wide variety of applications. These features mean a consistently high quality connection at a low installed cost. Copper compression connectors are manufactured from high-conductivity electrolytic copper. The connectors are normally tinplated, lead-plated, or plated with proprietary BURNDY® brite finish to provide durable long-lasting corrosion resistance. The connector design has been matched to the cable size to provide the necessary physical strength requirements for reliable electrical performance.
Application For Code Conductor ARRA Compliant C Buy American Compliant C Catalog Number YA252LN Color Code Pink Country of Origin US EU RoHS Indicator Y Gross Weight Per Pack 0.1100 lb Gross Weight per Pack Metric 0.05 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8535908020 Height 0.51 in Height [Metric] 1.2954 cm Length 4.29 in Length [Metric] 10.8966 cm Returnable Y Standard UL 486A-486B Standards UL467, CSA Certified and RoHS Compliant Sub Brand HYLUG Type Standard Barrel, Tin Plated UNSPSC 39121405 UPC 11 78181050227 UPC 12 781810502273 Voltage Rating 35,000 V Width 0.83 in Width [Metric] 2.1082 cm Stock Status NONSTOCK Brand BURNDY® Manufacturer BURNDY® Material Copper For Code Conductor Features: UL Listed 90 DEG C, 600 V - 35 KV, 45 DEG And 90 DEG Angles Are Available, Temperature Rating: 90 DEG C, Finish: Electro-Tin Plated, Wire Strip Length: 15/16 IN, Tongue Angle: Straight, Die Index: 12, Tools, Die Set Catalog Number, And (number Of Crimps): Mechanical: MD6, OUR840, MD7-34R Tool, W25VT, W25RT, X25RT Die, (2), Hydraulic: BCT500HS, Y500CTHS Tool, W25VT, W25RT, X25RT Die, (2), Y35, Y39, Y750, PAT750 Tool, U25RT, U2CABT Die, (1), Y46 Tool, U25RT, U2CABT Die With PUADP-1 Adapter, (1), Color Code: Pink, Dieless Tools (number Of Crimps): Y644HS, Y81KFT, Y81KFTMBH, PAT81KFT-18V, MY29-3, MY29-11 Tool, (1), MRC840 Tool, (2), Conductor Type: Commercial Stranded Copper For mechanical: MD6, OUR840, MD7-34R tool, (2) W25VT, W25RT, X25RT die, hydraulic: BCT500HS, Y500CTHS tool, (2) W25VT, W25RT, X25RT die, Y35, Y39, Y750, PAT750 tool, (1) U25RT, U2CABT die, Y46 tool, (1) U25RT, U2CABT die with PUADP-1 adapter, dieless tools (number of crimps): (1) Y644HS, Y81KFT, Y81KFTMBH, PAT81KFT-18V, MY29-3, MY29-11 tool, (2) MRC840 tool installation tool 1/0 AWG stranded conductor size 15/16 in L Strip, 1-3/4 in Stud Hole Spacing Electro Tin Plated Copper
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | For Code Conductor |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | YA252LN |
| Color Code | Pink |
| Country of Origin | US |
| EU RoHS Indicator | Y |
| Gross Weight Per Pack | 0.1100 lb |
| Gross Weight per Pack Metric | 0.05 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8535908020 |
| Height | 0.51 in |
| Height [Metric] | 1.2954 cm |
| Length | 4.29 in |
| Length [Metric] | 10.8966 cm |
| Returnable | Y |
| Standard | UL 486A-486B |
| Standards | UL467, CSA Certified and RoHS Compliant |
| Sub Brand | HYLUG |
| Type | Standard Barrel, Tin Plated |
| UNSPSC | 39121405 |
| UPC 11 | 78181050227 |
| UPC 12 | 781810502273 |
| Voltage Rating | 35,000 V |
| Width | 0.83 in |
| Width [Metric] | 2.1082 cm |
| Stock Status | NONSTOCK |
| Brand | BURNDY® |
| Manufacturer | BURNDY® |
| Material | Copper |
| For Code Conductor |
| Features: UL Listed 90 DEG C, 600 V - 35 KV, 45 DEG And 90 DEG Angles Are Available, Temperature Rating: 90 DEG C, Finish: Electro-Tin Plated, Wire Strip Length: 15/16 IN, Tongue Angle: Straight, Die Index: 12, Tools, Die Set Catalog Number, And (number Of Crimps): Mechanical: MD6, OUR840, MD7-34R Tool, W25VT, W25RT, X25RT Die, (2), Hydraulic: BCT500HS, Y500CTHS Tool, W25VT, W25RT, X25RT Die, (2), Y35, Y39, Y750, PAT750 Tool, U25RT, U2CABT Die, (1), Y46 Tool, U25RT, U2CABT Die With PUADP-1 Adapter, (1), Color Code: Pink, Dieless Tools (number Of Crimps): Y644HS, Y81KFT, Y81KFTMBH, PAT81KFT-18V, MY29-3, MY29-11 Tool, (1), MRC840 Tool, (2), Conductor Type: Commercial Stranded Copper |
| For mechanical: MD6, OUR840, MD7-34R tool, (2) W25VT, W25RT, X25RT die, hydraulic: BCT500HS, Y500CTHS tool, (2) W25VT, W25RT, X25RT die, Y35, Y39, Y750, PAT750 tool, (1) U25RT, U2CABT die, Y46 tool, (1) U25RT, U2CABT die with PUADP-1 adapter, dieless tools (number of crimps): (1) Y644HS, Y81KFT, Y81KFTMBH, PAT81KFT-18V, MY29-3, MY29-11 tool, (2) MRC840 tool installation tool |
| 1/0 AWG stranded conductor size |
| 15/16 in L Strip, 1-3/4 in Stud Hole Spacing |
| Electro Tin Plated Copper |
