Blackburn® L35 Type L Compact Mechanical Terminal Lug, 14 to 8 AWG Stranded Solid Copper Conductor, 13/64 in Stud
Custom_Product_Images_Illustration
Blackburn® L35 Type L Compact Mechanical Terminal Lug, 14 to 8 AWG Stranded Solid Copper Conductor, 13/64 in Stud
SKU93532
MFGR #L35
Your Cost: $3.9293/ea($392.93 / c)
Blackburn® cast, forged, or formed mechanical connections, produced in economical copper and dual-rated aluminum, provide unequaled variety with a large variety of U.L. and C.S.A. certified solutions for your electrical interface needs.
Blackburn® cast, forged, or formed mechanical connections, produced in economical copper and dual-rated aluminum, provide unequaled variety with a large variety of U.L. and C.S.A. certified solutions for your electrical interface needs.
Alternate Catalog Number 7TAH006720R0027 ARRA Compliant C Brand Blackburn® Buy American Compliant C Catalog Number L35 Conductor Range [Main|Primary] 14 Sol.-8 Str. Conductor Size 14 to 8 AWG Conductor Type Stranded Solid Copper Country of Origin MX Currency USD Dimensions 13/16 in L x 3/8 in W x 3/8 in H EU RoHS Indicator C Gross Volume Per Pack 15.55 Gross Volume per Pack Metric 254.85 Gross Weight Per Pack 0.0050 lb Gross Weight per Pack Metric 0.01 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8535908020 Height 2.00 in Height [Metric] 5.0800 cm Item Group 1I Item Group 2 1IE Length 3.00 in Length [Metric] 7.6200 cm Manufacturer Thomas & Betts Material Copper Number of Bolt Holes 1 Returnable A Series 14 Sol.-8 Str. Specifications 1-Conductor, Socket, Screwdriver Slot Head Screw Standard UL E9809 Standards ARRA, Buy American Act and RoHS Compliant, CSA Certified, UL File No. E9809 Stock Status NORMALLY STOCKED Stud Size 13/64 in Tongue Size 1/2 in L x 3/8 in W x 3/32 in THK Tongue Style Straight Type Type L Compact UNSPSC 39121408 UPC 11 78378613001 UPC 12 783786130016 Width 2.50 in Width [Metric] 6.3500 cm Cold forged from pure electrolytic copper with 99 percent conductivity. Cold forged from pure electrolytic copper with 99 percent conductivity 1-piece construction for strength and durability Excellent for confined quarters Steel plated screw 1 stud of 13/64 in
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | 7TAH006720R0027 |
| ARRA Compliant | C |
| Brand | Blackburn® |
| Buy American Compliant | C |
| Catalog Number | L35 |
| Conductor Range [Main|Primary] | 14 Sol.-8 Str. |
| Conductor Size | 14 to 8 AWG |
| Conductor Type | Stranded Solid Copper |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 13/16 in L x 3/8 in W x 3/8 in H |
| EU RoHS Indicator | C |
| Gross Volume Per Pack | 15.55 |
| Gross Volume per Pack Metric | 254.85 |
| Gross Weight Per Pack | 0.0050 lb |
| Gross Weight per Pack Metric | 0.01 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8535908020 |
| Height | 2.00 in |
| Height [Metric] | 5.0800 cm |
| Item Group | 1I |
| Item Group 2 | 1IE |
| Length | 3.00 in |
| Length [Metric] | 7.6200 cm |
| Manufacturer | Thomas & Betts |
| Material | Copper |
| Number of Bolt Holes | 1 |
| Returnable | A |
| Series | 14 Sol.-8 Str. |
| Specifications | 1-Conductor, Socket, Screwdriver Slot Head Screw |
| Standard | UL E9809 |
| Standards | ARRA, Buy American Act and RoHS Compliant, CSA Certified, UL File No. E9809 |
| Stock Status | NORMALLY STOCKED |
| Stud Size | 13/64 in |
| Tongue Size | 1/2 in L x 3/8 in W x 3/32 in THK |
| Tongue Style | Straight |
| Type | Type L Compact |
| UNSPSC | 39121408 |
| UPC 11 | 78378613001 |
| UPC 12 | 783786130016 |
| Width | 2.50 in |
| Width [Metric] | 6.3500 cm |
| Cold forged from pure electrolytic copper with 99 percent conductivity. |
| Cold forged from pure electrolytic copper with 99 percent conductivity |
| 1-piece construction for strength and durability |
| Excellent for confined quarters |
| Steel plated screw |
| 1 stud of 13/64 in |
