Banner Engineering SM312FP1H SM312 Fiber Optic Sensor, Rectangle Shape, Visible Red Sensing Beam, 1 ms Response Time
Fiber Optic Block Style Sensors
46382
MFG #: SM312FP1H
BANNER®
148.03000
/ ea
Banner Engineering Fiber Optic Sensor, Series: SM312, Rectangle, Plastic Fiber Optic Sensing Method, Visible Red Sensing Beam, 1 ms Response, Single Discrete NPN/PNP Output, 10 to 30 VDC, 4-Pin Cable, LED Light Source, NEMA 1/2/3/3S/4/4X/6/12/IP67, -20 to 70 deg C Operating, Environmental Conditions: 90% at 50 deg C Maximum Relative Humidity
- bannerengineering.com(Seller Home Page URL)
- Compliance Cert URL - Banner_SM2A30PRLQD_Compliance_Certificate.pdf(Compliance Cert URL)
- Install Instructions URL - INS_61308_Ins.pdf(Install Instructions URL)
- Spec Sheet 1 URL - Banner_SM312FQD_Specification_Sheet_1.pdf(Spec Sheet 1 URL)
- Spec Sheet URL - SPE_66248825916_Spec.pdf(Spec Sheet URL)
- Tech Drawing URL - Banner_SM312FP1H_Technical_Drawing.pdf(Tech Drawing URL)
- Warranty URL - WAR_Banner_Warranty.pdf(Warranty URL)
- Features
| Thermoplastic primary housing material |
| 300 us repeatability |
| Mini-Beam scanner original fiber bezel visible red, 650 nm plastic fiber optic |
| Gain (sensitivity) adjustment screw |
| Alignment indicator device |
| Light/dark operate select switch |
| Clockwise light operate (outputs conduct when sensing light is received) |
| Counter clockwise dark operate (outputs conduct when sensing light is not received) |
| 4-pins 2 m cable connection |
| Indicator LEDs display |
| Potentiometer adjustment |
| 100 ms delay at power-up |
| 4-pin 2 m cable connection |
