Baldor-Reliance L3505 AC Motor, 115/230 VAC, 3.9/7.8 A, 56 Frame, 0.5 hp, 1140 rpm
Custom_Product_Images_Illustration
Baldor-Reliance L3505 AC Motor, 115/230 VAC, 3.9/7.8 A, 56 Frame, 0.5 hp, 1140 rpm
SKU320185
MFGR #L3505
Your Cost: $1,037.06/ea
List: Baldor-Reliance AC Motor, 115/230 VAC, 3.9/7.8 A, 60 Hz, 0.5 hp, 1, 1140 rpm, 1 Speed, TEFC, 56 Frame, 5/8 in Dia Shaft, Reversible, Service Factor: 1.25, Ball Bearing, 4.88 ft-lb, F1 Mount, 40 deg C, Insulation Class: F, Steel, 12.91 in L x 9.89 in W x 9.05 in H
Baldor-Reliance AC Motor, 115/230 VAC, 3.9/7.8 A, 60 Hz, 0.5 hp, 1, 1140 rpm, 1 Speed, TEFC, 56 Frame, 5/8 in Dia Shaft, Reversible, Service Factor: 1.25, Ball Bearing, 4.88 ft-lb, F1 Mount, 40 deg C, Insulation Class: F, Steel, 12.91 in L x 9.89 in W x 9.05 in H
Application General purpose Base Rigid Brand Baldor-Reliance Catalog Number L3505 Country of Origin US Duty Continuous Enclosure TEFC Frame 56 Frequency Rating 60 Hz Full Load Current 3.9/7.8 A Gross Weight Per Pack 43.0000 lb Horsepower 0.5 hp Insulation Class F Manufacturer Baldor-Reliance (ABB) Mounting F1 NEMA DESIGN N Phase 1 Power Factor 1.00 Rotation Reversible Service Factor 1 Speed Rating 1,140 rpm Standards CSA Certified, UL Listed, RoHS Compliant, NEMA Stock Status NONSTOCK Type AC Motors UNSPSC 26101112 UPC 11 78156810029 UPC 12 78156810029 Voltage Rating 115/230 V General Purpose .5HP,1140RPM,1PH,60HZ,56H,3528L,TEFC,F1 Snap action starting switch Gasketed conduit box and capacitor cover Base seam is welded to the frame 65 power factor Rigid base Continuous duty
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | General purpose |
| Base | Rigid |
| Brand | Baldor-Reliance |
| Catalog Number | L3505 |
| Country of Origin | US |
| Duty | Continuous |
| Enclosure | TEFC |
| Frame | 56 |
| Frequency Rating | 60 Hz |
| Full Load Current | 3.9/7.8 A |
| Gross Weight Per Pack | 43.0000 lb |
| Horsepower | 0.5 hp |
| Insulation Class | F |
| Manufacturer | Baldor-Reliance (ABB) |
| Mounting | F1 |
| NEMA DESIGN | N |
| Phase | 1 |
| Power Factor | 1.00 |
| Rotation | Reversible |
| Service Factor | 1 |
| Speed Rating | 1,140 rpm |
| Standards | CSA Certified, UL Listed, RoHS Compliant, NEMA |
| Stock Status | NONSTOCK |
| Type | AC Motors |
| UNSPSC | 26101112 |
| UPC 11 | 78156810029 |
| UPC 12 | 78156810029 |
| Voltage Rating | 115/230 V |
| General Purpose |
| .5HP,1140RPM,1PH,60HZ,56H,3528L,TEFC,F1 |
| Snap action starting switch |
| Gasketed conduit box and capacitor cover |
| Base seam is welded to the frame |
| 65 power factor |
| Rigid base |
| Continuous duty |
