Appleton® Unilet® FS-2EXT Type FS Heavy Duty Device Box, Malleable Iron, 2 Gangs
Custom_Product_Images_Illustration
Appleton® Unilet® FS-2EXT Type FS Heavy Duty Device Box, Malleable Iron, 2 Gangs
SKU288080
MFGR #FS2EXT
Your Cost: $60.88/ea
Appleton® Unilet® Device Box, Type FS Heavy Duty, 2 Gangs, 1 in Hub, Surface Mount, Malleable Iron, 2 in H
Appleton® Unilet® Device Box, Type FS Heavy Duty, 2 Gangs, 1 in Hub, Surface Mount, Malleable Iron, 2 in H
Application For Use With Unilets FS Two Gang Cast Device Boxes ARRA Compliant Y Buy American Compliant N Catalog Number FS2EXT Country of Origin MX Currency USD EU RoHS Indicator C Gross Weight Per Pack 0.8800 lb Gross Weight per Pack Metric 0.40 Gross Weight UOM Metric kg Height 0.27 in Height [Metric] 6.8072 mm Hub Size 1 in Length 13.90 in Length [Metric] 35.3060 cm Mounting Box Mounting Type Surface Size 1 IN Extension Standard UL 514A, UL File Number E2527, NEMA FB-1, OS-1 Standards ARRA CompliantRoHS Compliant Sub Brand UNILETS Type Type FS Heavy Duty UNSPSC 39121315 UPC 11 78138134205 UPC 12 781381342056 Width 14.40 in Width [Metric] 36.5760 cm Stock Status NONSTOCK Brand Appleton™ Manufacturer Appleton Dimensions 2 in H Material Malleable Iron Number of Gangs 2 For Use With Unilets FS Two Gang Cast Device Boxes Corrosion-resistant ideal for indoor and outdoor installations; Weatherproof, raintight and dust tight when used with cast gasketed covers; Malleable iron for high tensile strength and ductility provides greater resistance to impact and shock; Both malleable iron and aluminum boxes have ridge top construction for positive cover/gasket/box fit; Accurately tapped, tapered threads for tight, rigid joints, ground continuity Malleable iron or copper-free aluminum boxes with epoxy powder coat finish, malleable iron, copper-free aluminum or steel covers, captive stainless steel screws, neoprene gaskets Rugged and corrosion resistant for indoor or outdoor use Weatherproof, raintight and dust tight when used with cast gasketed covers FS and FD boxes take standard flush wiring devices, FD boxes take devices exceeding 1-5/8 in D under fastening ears Ridge top construction provides positive fit between gasket, box and cover to seal out moisture Furnished with internal grounding screw Triple coat (zinc electroplate, chromate and epoxy powder coat)
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | For Use With Unilets FS Two Gang Cast Device Boxes |
| ARRA Compliant | Y |
| Buy American Compliant | N |
| Catalog Number | FS2EXT |
| Country of Origin | MX |
| Currency | USD |
| EU RoHS Indicator | C |
| Gross Weight Per Pack | 0.8800 lb |
| Gross Weight per Pack Metric | 0.40 |
| Gross Weight UOM Metric | kg |
| Height | 0.27 in |
| Height [Metric] | 6.8072 mm |
| Hub Size | 1 in |
| Length | 13.90 in |
| Length [Metric] | 35.3060 cm |
| Mounting | Box |
| Mounting Type | Surface |
| Size | 1 IN Extension |
| Standard | UL 514A, UL File Number E2527, NEMA FB-1, OS-1 |
| Standards | ARRA CompliantRoHS Compliant |
| Sub Brand | UNILETS |
| Type | Type FS Heavy Duty |
| UNSPSC | 39121315 |
| UPC 11 | 78138134205 |
| UPC 12 | 781381342056 |
| Width | 14.40 in |
| Width [Metric] | 36.5760 cm |
| Stock Status | NONSTOCK |
| Brand | Appleton™ |
| Manufacturer | Appleton |
| Dimensions | 2 in H |
| Material | Malleable Iron |
| Number of Gangs | 2 |
| For Use With Unilets FS Two Gang Cast Device Boxes |
| Corrosion-resistant ideal for indoor and outdoor installations; Weatherproof, raintight and dust tight when used with cast gasketed covers; Malleable iron for high tensile strength and ductility provides greater resistance to impact and shock; Both malleable iron and aluminum boxes have ridge top construction for positive cover/gasket/box fit; Accurately tapped, tapered threads for tight, rigid joints, ground continuity |
| Malleable iron or copper-free aluminum boxes with epoxy powder coat finish, malleable iron, copper-free aluminum or steel covers, captive stainless steel screws, neoprene gaskets |
| Rugged and corrosion resistant for indoor or outdoor use |
| Weatherproof, raintight and dust tight when used with cast gasketed covers |
| FS and FD boxes take standard flush wiring devices, FD boxes take devices exceeding 1-5/8 in D under fastening ears |
| Ridge top construction provides positive fit between gasket, box and cover to seal out moisture |
| Furnished with internal grounding screw |
| Triple coat (zinc electroplate, chromate and epoxy powder coat) |
