Appleton® CES-6023 Pin and Sleeve Receptacle, 125/250 VAC, 60 A, 3 Poles, 2 Wires
SKU128479
MFGR #CES6023
Your Cost: $1,466.96/ea
Appleton® Pin and Sleeve Receptacle, 125/250 VAC, 60 A, 1-1/2 hp, 3 Poles, 2 Wires, Pressure Wire Terminal, Aluminum, 6.88 in W x 11.88 in H
Appleton® Pin and Sleeve Receptacle, 125/250 VAC, 60 A, 1-1/2 hp, 3 Poles, 2 Wires, Pressure Wire Terminal, Aluminum, 6.88 in W x 11.88 in H
ARRA Compliant C Buy American Compliant N Catalog Number CES6023 Country of Origin MX Currency USD Dimensions 11.88 in H x 6.88 in W EU RoHS Indicator C Gross Weight Per Pack 16.0000 lb Height 6.50 in Height [Metric] 16.5100 cm Horsepower 1-1/2 hp Length 12.00 in Length [Metric] 30.4800 cm Material Copper Free Aluminum Number Of Poles 3 Series CES Standards CSA C22.2 Certified, RoHS Complaint, UL 894/1010/1682/1686 Listed Terminal Type Pressure Wired Type Feed Through Grounding Style 2 UNSPSC 39121406 UPC 11 78138118810 UPC 12 781381188104 Width 9.60 in Width [Metric] 24.3840 cm Stock Status NONSTOCK Brand Appleton™ Manufacturer Appleton Amperage Rating 60 A Number of Wires 2 Voltage Rating 125 to 250 VAC Furnished with one vertical and two horizontal feed-through hubs Explosion proof Delayed-action safety construction with Slide-Lok design Factory sealed: no external seals required, arcing is safely confined to receptacle interior Energized receptacle contacts deeply recessed to reduce danger of accidental touching Spring door keeps dust out of receptacle when plug is not in use Unique design brass contacts exert constant pressure along entire contact surface and provide superior electrical contact Contacts have beryllium copper wire springs Insulators provide superior dielectric and mechanical strength and lowest arc tracking Smooth, rounded integral bushing in each hub protects conductor insulation Fiber glass reinforced polyester insulating blocks; For lighting systems, conveyors, heaters, motor-generator sets, air conditioners, compressors, pumps Ceramic burnished copper-free aluminum
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| ARRA Compliant | C |
| Buy American Compliant | N |
| Catalog Number | CES6023 |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 11.88 in H x 6.88 in W |
| EU RoHS Indicator | C |
| Gross Weight Per Pack | 16.0000 lb |
| Height | 6.50 in |
| Height [Metric] | 16.5100 cm |
| Horsepower | 1-1/2 hp |
| Length | 12.00 in |
| Length [Metric] | 30.4800 cm |
| Material | Copper Free Aluminum |
| Number Of Poles | 3 |
| Series | CES |
| Standards | CSA C22.2 Certified, RoHS Complaint, UL 894/1010/1682/1686 Listed |
| Terminal Type | Pressure Wired |
| Type | Feed Through Grounding Style 2 |
| UNSPSC | 39121406 |
| UPC 11 | 78138118810 |
| UPC 12 | 781381188104 |
| Width | 9.60 in |
| Width [Metric] | 24.3840 cm |
| Stock Status | NONSTOCK |
| Brand | Appleton™ |
| Manufacturer | Appleton |
| Amperage Rating | 60 A |
| Number of Wires | 2 |
| Voltage Rating | 125 to 250 VAC |
| Furnished with one vertical and two horizontal feed-through hubs |
| Explosion proof |
| Delayed-action safety construction with Slide-Lok design |
| Factory sealed: no external seals required, arcing is safely confined to receptacle interior |
| Energized receptacle contacts deeply recessed to reduce danger of accidental touching |
| Spring door keeps dust out of receptacle when plug is not in use |
| Unique design brass contacts exert constant pressure along entire contact surface and provide superior electrical contact |
| Contacts have beryllium copper wire springs |
| Insulators provide superior dielectric and mechanical strength and lowest arc tracking |
| Smooth, rounded integral bushing in each hub protects conductor insulation |
| Fiber glass reinforced polyester insulating blocks; For lighting systems, conveyors, heaters, motor-generator sets, air conditioners, compressors, pumps |
| Ceramic burnished copper-free aluminum |
