Amprobe® Navigator™ ACDC-54NAV Clamp Meter, 1000 VAC/VDC, 1000A, 100 kOhm, 20 Hz to 10 KHz, 40 mm Jaw, Backlight Display
Custom_Product_Images_Illustration
Amprobe® Navigator™ ACDC-54NAV Clamp Meter, 1000 VAC/VDC, 1000A, 100 kOhm, 20 Hz to 10 KHz, 40 mm Jaw, Backlight Display
SKU650054
MFGR #ACDC-54NAV
Your Cost: $699.99/ea
This clamp-on multimeter offers a full range of power quality diagnostics including power and power factor, total harmonics distortion, individual harmonics, in-rush current, phase sequence, TRMS and low pass filter for industrial power monitoring and verifying system conditions
This clamp-on multimeter offers a full range of power quality diagnostics including power and power factor, total harmonics distortion, individual harmonics, in-rush current, phase sequence, TRMS and low pass filter for industrial power monitoring and verifying system conditions
AC Current Accuracy +/-1.5 % RDG + 5 LSD Alternate Catalog Number 3729989 Application Electrical ARRA Compliant N Buy American Compliant N Catalog Number ACDC-54NAV Country of Origin TW Counts 10000 Currency USD Dimensions 10.2 in L x 3.4 in W x 2 in H EU RoHS Indicator U Gross Weight Per Pack 0.9300 lb Gross Weight per Pack Metric 0.42 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 9030310000 Height 2.00 in Height [Metric] 5.0800 cm Jaw size 1.60” (40mm) Length 9.40 in Length [Metric] 23.8760 cm Operating Temperature 0 to 10 °C Power Accuracy +/-2.5 % RDG + 5 LSD at 10 to 1000 kW Power Source 9 VDC AA Alkaline Battery Safety Rating Cat IV 600 V Standards CE MarkedcULus ListedPROP65: This product is in compliance with PROP65; it is not known to contain any chemicals associated with this regulation Type AC/DC True RMS UNSPSC 41113678 UPC 11 09596955667 UPC 12 095969556675 Voltage Accuracy +/-1% RDG + 5 LSD for VAC, +/-0.7% RDG + 2 LSD for VDC Voltage Rating 100.00 V, 1000 V AC/DC Width 3.40 in Width [Metric] 8.6360 cm Stock Status NONSTOCK Brand Fluke® Manufacturer Fluke Corporation Display Type Large Backlit LCD Electrical Ratings 100 to 1000 A AC/DC, 100 to 1000 VAC/VDC Frequency Rating 20 Hz to 10 kHz Jaw Capacity 1.6 in Resistance 1 to 100 kOhm electrical This clamp-on multimeter offers a full range of power quality diagnostics including power and power factor, total harmonics distortion, individual harmonics, in-rush current, phase sequence, TRMS and low pass filter for industrial power monitoring and verifying system conditions. True rms technology improves accuracy in noisy environments Includes inrush current measurement and phase rotation indication for 3-phase motors Non-contact voltage detection enhances safety Low pass filter allows measurement of voltage and frequency of variable frequency drives Continuity beeper quickly identifies shorts and opens Large backlit digital display with analog bar graph presents the full picture Maximum, minimum and smart data hold Peak hold identifies spikes and transients In-jaw flashlight automatically lights when jaws open to illuminate dark panels and junction boxes Auto power off conserves battery life Maximum jaw opening accommodates large conductors up to 1.6 in Rubber over mold body absorbs shocks - drop proof to 4 ft +/-1% RDG + 3 LSD resistance accuracy +/-0.5% RDG + 3 LSD frequency accuracy Measures AC/DC voltage to 1000 VAC/VDC, AC/DC current to 1000 A, plus resistance, frequency, capacitance, power and power factor, total harmonics distortion (THD) and individual harmonics from 1 to 25 -50 to 1832 deg F temperature range measures
content loaded
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Media
- Substitute Products
| AC Current Accuracy | +/-1.5 % RDG + 5 LSD |
| Alternate Catalog Number | 3729989 |
| Application | Electrical |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | ACDC-54NAV |
| Country of Origin | TW |
| Counts | 10000 |
| Currency | USD |
| Dimensions | 10.2 in L x 3.4 in W x 2 in H |
| EU RoHS Indicator | U |
| Gross Weight Per Pack | 0.9300 lb |
| Gross Weight per Pack Metric | 0.42 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 9030310000 |
| Height | 2.00 in |
| Height [Metric] | 5.0800 cm |
| Jaw size | 1.60” (40mm) |
| Length | 9.40 in |
| Length [Metric] | 23.8760 cm |
| Operating Temperature | 0 to 10 °C |
| Power Accuracy | +/-2.5 % RDG + 5 LSD at 10 to 1000 kW |
| Power Source | 9 VDC AA Alkaline Battery |
| Safety Rating | Cat IV 600 V |
| Standards | CE MarkedcULus ListedPROP65: This product is in compliance with PROP65; it is not known to contain any chemicals associated with this regulation |
| Type | AC/DC True RMS |
| UNSPSC | 41113678 |
| UPC 11 | 09596955667 |
| UPC 12 | 095969556675 |
| Voltage Accuracy | +/-1% RDG + 5 LSD for VAC, +/-0.7% RDG + 2 LSD for VDC |
| Voltage Rating | 100.00 V, 1000 V AC/DC |
| Width | 3.40 in |
| Width [Metric] | 8.6360 cm |
| Stock Status | NONSTOCK |
| Brand | Fluke® |
| Manufacturer | Fluke Corporation |
| Display Type | Large Backlit LCD |
| Electrical Ratings | 100 to 1000 A AC/DC, 100 to 1000 VAC/VDC |
| Frequency Rating | 20 Hz to 10 kHz |
| Jaw Capacity | 1.6 in |
| Resistance | 1 to 100 kOhm |
| electrical |
| This clamp-on multimeter offers a full range of power quality diagnostics including power and power factor, total harmonics distortion, individual harmonics, in-rush current, phase sequence, TRMS and low pass filter for industrial power monitoring and verifying system conditions. |
| True rms technology improves accuracy in noisy environments |
| Includes inrush current measurement and phase rotation indication for 3-phase motors |
| Non-contact voltage detection enhances safety |
| Low pass filter allows measurement of voltage and frequency of variable frequency drives |
| Continuity beeper quickly identifies shorts and opens |
| Large backlit digital display with analog bar graph presents the full picture |
| Maximum, minimum and smart data hold |
| Peak hold identifies spikes and transients |
| In-jaw flashlight automatically lights when jaws open to illuminate dark panels and junction boxes |
| Auto power off conserves battery life |
| Maximum jaw opening accommodates large conductors up to 1.6 in |
| Rubber over mold body absorbs shocks - drop proof to 4 ft |
| +/-1% RDG + 3 LSD resistance accuracy |
| +/-0.5% RDG + 3 LSD frequency accuracy |
| Measures AC/DC voltage to 1000 VAC/VDC, AC/DC current to 1000 A, plus resistance, frequency, capacitance, power and power factor, total harmonics distortion (THD) and individual harmonics from 1 to 25 |
| -50 to 1832 deg F temperature range measures |
