Aluminum Compression Lug, 2 Hole, 400 kc
Lug Compression Connectors
215442
MFG #: LAB400-12-2
Panduit®
6793.74000
/ ea
Panduit® Compression Lug Connector, 2-Hole, Series: LAB, Aluminum/Copper Conductor, 400 kcmil Conductor, Die Code: P94, 35 kVAC, 1/2 in Stud, Straight Tongue, 1.66 in W x 0.38 in THK Tongue, 6.92 in Overall Length, Long, 2.55 in L Barrel, 2-9/16 in Wire Stripe Length, 90 deg C, Aluminum, Green
- http://www.panduit.com(Seller Home Page URL)
- Install Instructions 1 URL - 10965_7J0G6Z1UNWDKFX5O.pdf(Install Instructions 1 URL)
- Install Instructions 1 URL - 10965_FMB1ZA0D5XLH6NOU.pdf(Install Instructions 1 URL)
- Install Instructions URL - N-PCT-PMPI-227-PC--REV06--ENG.pdf(Install Instructions URL)
- Line Drawing URL(Line Drawing URL)
- Install Instructions 1 URL - N-PCT-PMPI-227-PC--REV06--ENG.pdf(Install Instructions 1 URL)
- Tech Drawing URL - 10965_ZB6X5OW20CJNELPT.pdf(Tech Drawing URL)
- Tech Drawing URL - C-PCLAB1000-12-1--ENG.pdf(Tech Drawing URL)
- Spec Sheet URL - C-PCLAB800-12-1--ENG.pdf(Spec Sheet URL)
- Features
| Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V |
| Tin-plated to inhibit corrosion |
| Color-coded end plug and Panduit and specified competitor die index numbers marked on barrel for proper crimp die selection |
| Manufactured from high conductivity thick wall wrought aluminum |
| Factory pre-filled with joint compound and sealed with easy pull-out end plug to inhibit corrosion |
| Enclosed barrel prevents corrosive material from entering barrel when used in harsh environments |
| 1.75 in stud hole spacing |
