Aluminum Compression Lug, 2 Hole, 2/0 AW
Lug Compression Connectors
412908
MFG #: LAB2/0-12-5
Panduit®
3419.11000
/ ea
Panduit® Compression Lug Connector, 2-Hole, Series: LAB, Aluminum/Copper Conductor, 2/0 AWG Conductor, Die Code: P54, 35 kVAC, 1/2 in Stud, Straight Tongue, 0.94 in W x 0.25 in THK Tongue, 5.55 in Overall Length, Long, 1.55 in L Barrel, 1-9/16 in Wire Stripe Length, 90 deg C, Aluminum, Olive
- http://www.panduit.com(Seller Home Page URL)
- Install Instructions 1 URL - 10965_7J0G6Z1UNWDKFX5O.pdf(Install Instructions 1 URL)
- Install Instructions URL - N-PCT-PMPI-227-PC--REV06--ENG.pdf(Install Instructions URL)
- Line Drawing URL(Line Drawing URL)
- Spec Sheet URL - 10965_TZWLBVMSFA9N4J2X.pdf(Spec Sheet URL)
- Tech Drawing URL - 10965_U319ECS8HA0FVR7I.pdf(Tech Drawing URL)
- Features
| Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V |
| Tin-plated to inhibit corrosion |
| Color-coded end plug and Panduit and specified competitor die index numbers marked on barrel for proper crimp die selection |
| Manufactured from high conductivity thick wall wrought aluminum |
| Factory pre-filled with joint compound and sealed with easy pull-out end plug to inhibit corrosion |
| Enclosed barrel prevents corrosive material from entering barrel when used in harsh environments |
| 1.75 in stud hole spacing |
