800A 3P 600V 3W NON-FUSED HD TYPE 1
SKU284759
MFGR #HNF367
Your Cost: $4,712.03/ea
List: Siemens SpeedFax™ Heavy Duty Safety Switch, Enclosed Low Voltage Non-Fusible, 600 VAC, 800 A, 500 hp, 3 Phase, 60 Hz, 3 Poles, 3 Wires, 200 kA Short Circuit, TPST, Lever Actuator, NEMA 1, Surface Mount, Lug Terminal, -20 to 120 deg F, 54.67 in H x 38.4 in W x 14.68 in D, Steel
Siemens SpeedFax™ Heavy Duty Safety Switch, Enclosed Low Voltage Non-Fusible, 600 VAC, 800 A, 500 hp, 3 Phase, 60 Hz, 3 Poles, 3 Wires, 200 kA Short Circuit, TPST, Lever Actuator, NEMA 1, Surface Mount, Lug Terminal, -20 to 120 deg F, 54.67 in H x 38.4 in W x 14.68 in D, Steel
Actuator SINGLETHROW Actuator Type Lever Operated Alternate Catalog Number US2:HNF367 Application DISCONNECTINGMEANFORSERVICEENTRANCE/LOADS ARRA Compliant C Buy American Compliant C Catalog Number HNF367 Connection MECHANICALLUGS Country of Origin MX Currency USD Dimensions 54.67 in H x 38.4 in W x 14.68 in D Enclosure NEMA1 Enclosure Type NEMA 1 EU RoHS Indicator C Frequency Rating 60 Hz Gross Volume Per Pack 37668.15 Gross Volume UOM in Gross Weight Per Pack 270.0000 lb Gross Weight per Pack Metric 122.47 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536509045 Height 12.0000 in Height [Metric] 30.4800 cm Insulation Type Non-Insulated Length 73.0000 in Length [Metric] 185.4200 cm Material Steel Mounting Surface Mounting Type 2/3-Point Hole Number Of Poles 3 Number of Wires 3 Operating Cycles 3500 Operating Temperature -29 °C Phase 3 Returnable Y Short Circuit Current Rating 200 kA Standard UL98 Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL Listed Sub Brand VBII Switch Type SINGLETHROW Temperature Rating -20 to 120 °F Terminal Type Lug Type Enclosed Heavy Duty Low Voltage Non-Fused UNSPSC 39122205 UPC 11 78364315123 UPC 12 783643151239 Width 43.0000 in Width [Metric] 109.2200 cm Stock Status NONSTOCK Brand Siemens Manufacturer Siemens Amperage Rating 800 A Contact Form TPST Horsepower 500 hp Voltage Rating 600 VAC DISCONNECTINGMEANFORSERVICEENTRANCE/LOADS Quick-make, quick-break operating mechanism that ensures positive operation Visible blade, double break switching action Arc chutes dissipate heat and prolong switch life Highly visible red handle grip designed for hook stick operation Defeatable dual cover interlock, center punch provided for field drilling to allow on padlocking Center punch provided for field drilling to allow on padlocking Handle can be padlocked in the off position with up to (3) padlocks with 5/16 in hasps Generous top, bottom and side gutters that meet or exceed NEC® wire bending space requirements Informative door labeling which includes replacement parts list Tangential knockouts through 600 A for easy conduit lineup Side hinged door that opens 180 deg for easier wiring Unique enclosure design increases rigidity and prevents cuts and scrapes to conductors and installers hands Spring reinforced fuse clips that assure reliable contact for cool operation Door latch securely holds door closed and allows cover padlocking Front removable mechanical lugs that are suitable for copper aluminum 60 or 75 deg C conductors Lugs are field convertible to copper body and to a wide variety of compression connectors Hinged clear line terminal shield with probe holes for inspecting or testing line side terminals Embossed aluminum nameplate on heavy duty switches provides highly visible ON/OFF indication Drawn cover for increased rigidity and resistance to abuse Top key hole and bottom mounting holes provide easy 2 or 3-point mounting
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator | SINGLETHROW |
| Actuator Type | Lever Operated |
| Alternate Catalog Number | US2:HNF367 |
| Application | DISCONNECTINGMEANFORSERVICEENTRANCE/LOADS |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | HNF367 |
| Connection | MECHANICALLUGS |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 54.67 in H x 38.4 in W x 14.68 in D |
| Enclosure | NEMA1 |
| Enclosure Type | NEMA 1 |
| EU RoHS Indicator | C |
| Frequency Rating | 60 Hz |
| Gross Volume Per Pack | 37668.15 |
| Gross Volume UOM | in |
| Gross Weight Per Pack | 270.0000 lb |
| Gross Weight per Pack Metric | 122.47 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536509045 |
| Height | 12.0000 in |
| Height [Metric] | 30.4800 cm |
| Insulation Type | Non-Insulated |
| Length | 73.0000 in |
| Length [Metric] | 185.4200 cm |
| Material | Steel |
| Mounting | Surface |
| Mounting Type | 2/3-Point Hole |
| Number Of Poles | 3 |
| Number of Wires | 3 |
| Operating Cycles | 3500 |
| Operating Temperature | -29 °C |
| Phase | 3 |
| Returnable | Y |
| Short Circuit Current Rating | 200 kA |
| Standard | UL98 |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL Listed |
| Sub Brand | VBII |
| Switch Type | SINGLETHROW |
| Temperature Rating | -20 to 120 °F |
| Terminal Type | Lug |
| Type | Enclosed Heavy Duty Low Voltage Non-Fused |
| UNSPSC | 39122205 |
| UPC 11 | 78364315123 |
| UPC 12 | 783643151239 |
| Width | 43.0000 in |
| Width [Metric] | 109.2200 cm |
| Stock Status | NONSTOCK |
| Brand | Siemens |
| Manufacturer | Siemens |
| Amperage Rating | 800 A |
| Contact Form | TPST |
| Horsepower | 500 hp |
| Voltage Rating | 600 VAC |
| DISCONNECTINGMEANFORSERVICEENTRANCE/LOADS |
| Quick-make, quick-break operating mechanism that ensures positive operation |
| Visible blade, double break switching action |
| Arc chutes dissipate heat and prolong switch life |
| Highly visible red handle grip designed for hook stick operation |
| Defeatable dual cover interlock, center punch provided for field drilling to allow on padlocking |
| Center punch provided for field drilling to allow on padlocking |
| Handle can be padlocked in the off position with up to (3) padlocks with 5/16 in hasps |
| Generous top, bottom and side gutters that meet or exceed NEC® wire bending space requirements |
| Informative door labeling which includes replacement parts list |
| Tangential knockouts through 600 A for easy conduit lineup |
| Side hinged door that opens 180 deg for easier wiring |
| Unique enclosure design increases rigidity and prevents cuts and scrapes to conductors and installers hands |
| Spring reinforced fuse clips that assure reliable contact for cool operation |
| Door latch securely holds door closed and allows cover padlocking |
| Front removable mechanical lugs that are suitable for copper aluminum 60 or 75 deg C conductors |
| Lugs are field convertible to copper body and to a wide variety of compression connectors |
| Hinged clear line terminal shield with probe holes for inspecting or testing line side terminals |
| Embossed aluminum nameplate on heavy duty switches provides highly visible ON/OFF indication |
| Drawn cover for increased rigidity and resistance to abuse |
| Top key hole and bottom mounting holes provide easy 2 or 3-point mounting |
