- Alternate Catalog Number: 7TAH007330R0034
- Application: Negative
- ARRA Compliant: C
- Brand: Color-Keyed®
- Buy American Compliant: C
- Catalog Number: BAC20SNBT
- Country of Origin: US
- Currency: USD
- EU RoHS Indicator: C
- Gross Volume Per Pack: 0.01
- Gross Volume per Pack Metric: 0.00
- Gross Weight Per Pack: 0.1600 lb
- Gross Weight per Pack Metric: 0.07
- Gross Weight UOM Metric: kg
- Harmonization Tariff Schedule Code: 8536904000
- Height: 2.30 in
- Height [Metric]: 5.8420 cm
- Item Group: 1M
- Item Group 2: 1ML
- Length: 4.50 in
- Length [Metric]: 11.4300 cm
- Manufacturer: Thomas & Betts
- Material: Copper
- Returnable: A
- Standards: ARRA CompliantBuy American Act CompliantRoHS Compliant
- Stock Status: NONSTOCK
- Sub Brand: Color Keyed
- Type: Heavy-Duty Battery Connector
- UNSPSC: 39121454
- UPC 11: 78621097287
- UPC 12: 786210972879
- Width: 2.30 in
- Width [Metric]: 5.8420 cm
Color-Keyed® connectors not only identify the correct installing die to be used for positive compressions, but also indicate the proper placement of the die on the connector. This is done by the bands of color on the connector which match the color on the dies. Compression is made between or on these color bands. The color name is also spelled on the connector as an added means of identification.
