Panduit® S1/0-56R-C Tubular Ring Terminal, Copper, Metallic
Crimp Terminals & Splices Kits
961262
MFG #: S1/0-56R-C
Panduit®
2878.19000
/ ea
- Amperage Rating: NA
- ARRA Compliant: Y
- Buy American Compliant: Y
- Cable Size: 1/0 AWG
- Catalog Number: S1/0-56R-C
- Connection: Beveled
- Country of Origin: MEX
- Currency: USD
- EU RoHS Indicator: Y
- Gross Volume UOM: CF
- Gross Volume UOM Metric: m3
- Gross Weight Per Pack: 4.6000 lb
- Gross Weight per Pack Metric: 2.09
- Gross Weight UOM Metric: kg
- Height: 3.45 in
- Height [Metric]: 8.7630 cm
- Insulation: None
- Length: 7.60 in
- Length [Metric]: 19.3040 cm
- Mounting: 5/8
- Number Of Holes: 1
- Returnable: Y
- Stud Size: 5/16 in
- Sub Brand: Pan-Lug?„?
- Type: Loose Piece Ring Terminal
- UNSPSC: 39121405
- UPC 11: 07498360034
- UPC 12: 07498360034
- Voltage Rating: NA V
- Width: 3.40 in
- Width [Metric]: 8.6360 cm
- Stock Status: NONSTOCK
- Brand: Panduit®
- Manufacturer: Panduit®
- Color: Metallic
- Material: Tin-Plated Copper
Panduit® Tubular Ring Terminal, 1/0 AWG, Copper, 35 KV, Metallic, 1.7 in L x 0.76 in W
- http://www.panduit.com(Seller Home Page URL)
- Install Instructions 1 URL - 10965_3JV71HEPAYQGR8B0.pdf(Install Instructions 1 URL)
- Install Instructions 1 URL - 10965_T1U7DIJM4ZF6NKYV.pdf(Install Instructions 1 URL)
- Install Instructions URL - N-TMT-PMPI-304-PC--REV03--ENG.pdf(Install Instructions URL)
- Spec Sheet 1 URL - Panduit_S1_0_56R_C_Datasheet_1.pdf(Spec Sheet 1 URL)
- Spec Sheet URL - C-PCS8-10R--ENG.pdf(Spec Sheet URL)
- Tech Bulletin URL - 10965_4HBSMXIT3RPVYJL0.pdf(Tech Bulletin URL)
- Tech Drawing URL - 10965_VCOR5PUI24XAT1YL.pdf(Tech Drawing URL)
- Video - https://www.panduit.com/content/dam/panduit/en/products/media/7/77/277/5277/110185277.mp4(Video)
- Features
| Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V |
| 5/16 in stud size |
| Beveled barrel configuration |
| Seamless tubular barrel type |
| Non-insulated |
| Tinned plating |
| 5/8 in L wire strip |
| 90 deg C temperature rating |
| 0.58 L barrel |
| 0.76 in W tongue |
| 0.52 in OD barrel |
| Straight angle |
| Seamless tubular barrel provides a consistent high performance quality crimp |
| Round double thick tongue for reliable power applications |
| Barrel of terminal internally beveled to provide quick and easy wire insertion |
| Inspection window allows visual inspection of proper wire insertion |
