Greenlee® 7706SB Hydraulic Driver-Punch, Stainless Steel
SKU89583
MFGR #7706SB
Your Cost: $1,573.90/ea
Greenlee® Hydraulic Driver-Punch, Stainless Steel Housing
Greenlee® Hydraulic Driver-Punch, Stainless Steel Housing
Application For punching holes in mild steel, stainless steel, aluminum, brass, copper, fiberglass and plastics ARRA Compliant Y Buy American Compliant X Catalog Number 7706SB Consist Of 1 Quick Draw Flex® knockout driver Consist Of 2 1/2" - 2" conduit size Slug-Buster® punches Consist Of 3 1/2" - 2" conduit size dies Consist Of 4 7/16" short hydraulic draw stud Consist Of 5 3/4" short hydraulic draw stud Country of Origin USA Currency USD EU RoHS Indicator U For Conduit|Pipe Diameter 1/2 to 2 in Gross Volume Per Pack 2040.74 Gross Volume per Pack Metric 33441.81 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 16.3500 lb Gross Weight per Pack Metric 8.95 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8467891000 Height 5.30 in Height [Metric] 13.4620 cm Housing Material Stainless Steel Length 18.60 in Length [Metric] 47.2440 cm Material Punch up to 10 ga mild steel or 12 ga stainless steel Maximum Operating Force 8 t Size 1/2" - 2" conduit size knockouts (hole size: 0.89" - 2.42" or 22.5 mm - 61.5 mm) Standards ARRA Compliant Tool|Kit Kit Type 8-Ton Hydraulic Knockout Kit UNSPSC 27113204 UPC 11 78331010476 UPC 12 78331010476 Width 15.70 in Width [Metric] 39.8780 cm Stock Status NONSTOCK Brand Greenlee® Manufacturer Greenlee Textron For Max Stainless Steel Thickness 10 ga For punching holes in mild steel, stainless steel, aluminum, brass, copper, fiberglass and plastics Compact design for portability and fast, easy one-person operation. Slug-Buster® punch profile splits slugs for easy slug removal. Knurled edge on punches for better grip. New die design optimized for widest range of materials and drivers. Laser markings for quick part identification. Alignment markings for improved accuracy. Easy threading draw studs with "dog point" tip helps eliminate cross-threading. Hex key access for easy removal from tool. Works with all Greenlee knockouts up to 2". Flex Head allows for maximum flexibility in tight working areas. Punches, dies, draw studs and case made in the USA. Driver manufactured in the USA from US and global components. Compact, lightweight design for portability and fast, easy one person operation Develops 8 tons of hydraulic force for easy punching, even in 10 ga stainless steel, depending on individual punch capacities Quick Draw® is perfect for fast, straight-on front panel punching Quick Draw® 90's right angle driver head rotates over 180 deg for maximum flexibility in tight working areas Quick Draw® Flex allows unlimited driver orientation to simplify access to work area Can be used with non-round punches within the capacity of the tool Alignment markings improve punching accuracy and productivity when making holes Punches and dies are marked with catalog numbers and sizes for quick part identification
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | For punching holes in mild steel, stainless steel, aluminum, brass, copper, fiberglass and plastics |
| ARRA Compliant | Y |
| Buy American Compliant | X |
| Catalog Number | 7706SB |
| Consist Of 1 | Quick Draw Flex® knockout driver |
| Consist Of 2 | 1/2" - 2" conduit size Slug-Buster® punches |
| Consist Of 3 | 1/2" - 2" conduit size dies |
| Consist Of 4 | 7/16" short hydraulic draw stud |
| Consist Of 5 | 3/4" short hydraulic draw stud |
| Country of Origin | USA |
| Currency | USD |
| EU RoHS Indicator | U |
| For Conduit|Pipe Diameter | 1/2 to 2 in |
| Gross Volume Per Pack | 2040.74 |
| Gross Volume per Pack Metric | 33441.81 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 16.3500 lb |
| Gross Weight per Pack Metric | 8.95 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8467891000 |
| Height | 5.30 in |
| Height [Metric] | 13.4620 cm |
| Housing Material | Stainless Steel |
| Length | 18.60 in |
| Length [Metric] | 47.2440 cm |
| Material | Punch up to 10 ga mild steel or 12 ga stainless steel |
| Maximum Operating Force | 8 t |
| Size | 1/2" - 2" conduit size knockouts (hole size: 0.89" - 2.42" or 22.5 mm - 61.5 mm) |
| Standards | ARRA Compliant |
| Tool|Kit | Kit |
| Type | 8-Ton Hydraulic Knockout Kit |
| UNSPSC | 27113204 |
| UPC 11 | 78331010476 |
| UPC 12 | 78331010476 |
| Width | 15.70 in |
| Width [Metric] | 39.8780 cm |
| Stock Status | NONSTOCK |
| Brand | Greenlee® |
| Manufacturer | Greenlee Textron |
| For Max Stainless Steel Thickness | 10 ga |
| For punching holes in mild steel, stainless steel, aluminum, brass, copper, fiberglass and plastics |
| Compact design for portability and fast, easy one-person operation. Slug-Buster® punch profile splits slugs for easy slug removal. Knurled edge on punches for better grip. New die design optimized for widest range of materials and drivers. Laser markings for quick part identification. Alignment markings for improved accuracy. Easy threading draw studs with "dog point" tip helps eliminate cross-threading. Hex key access for easy removal from tool. Works with all Greenlee knockouts up to 2". Flex Head allows for maximum flexibility in tight working areas. Punches, dies, draw studs and case made in the USA. Driver manufactured in the USA from US and global components. |
| Compact, lightweight design for portability and fast, easy one person operation |
| Develops 8 tons of hydraulic force for easy punching, even in 10 ga stainless steel, depending on individual punch capacities |
| Quick Draw® is perfect for fast, straight-on front panel punching |
| Quick Draw® 90's right angle driver head rotates over 180 deg for maximum flexibility in tight working areas |
| Quick Draw® Flex allows unlimited driver orientation to simplify access to work area |
| Can be used with non-round punches within the capacity of the tool |
| Alignment markings improve punching accuracy and productivity when making holes |
| Punches and dies are marked with catalog numbers and sizes for quick part identification |
