Sandvik Coromant
Sandvik Coromant 5780215 Auto FS Milling Insert, SBEX 12 03 ZZ H13A, S-Square, SBEX Insert, Carbide, H13A, SBEX 12 03 ZZ H13A
Sandvik Coromant
Sandvik Coromant 5780215 Auto FS Milling Insert, SBEX 12 03 ZZ H13A, S-Square, SBEX Insert, Carbide, H13A, SBEX 12 03 ZZ H13A
SKU1244670
MFGR #5780215
Your Cost: $17.18/ea
List: Sandvik Coromant Milling Insert, Series: Auto FS, SBEX Insert, S-Square, 1/2 in Inscribed Circle, 1/8 in Thickness, 1/2 in Width, 1/2 in Length, 0.02 in Corner Radius, 5 deg Lead Angle, Manufacturer's Grade: H13A, ANSI Code: SBEX 12 03 ZZ H13A, ISO Code: SBEX 12 03 ZZ H13A, Neutral Hand, Carbide, Uncoated, Material Grade: K
Sandvik Coromant Milling Insert, Series: Auto FS, SBEX Insert, S-Square, 1/2 in Inscribed Circle, 1/8 in Thickness, 1/2 in Width, 1/2 in Length, 0.02 in Corner Radius, 5 deg Lead Angle, Manufacturer's Grade: H13A, ANSI Code: SBEX 12 03 ZZ H13A, ISO Code: SBEX 12 03 ZZ H13A, Neutral Hand, Carbide, Uncoated, Material Grade: K
ANSI Code SBEX 12 03 ZZ H13A Catalog Number 5780215 Corner Radius 0.02 in Country of Origin JP Finish Uncoated Gross Weight Per Pack 0.1800 lb Hand of Insert Neutral ISO Code SBEX 12 03 ZZ H13A Lead Angle 5 ° Length 1/2 in Material Application Cast Iron Series Auto FS Thickness 1/8 in Width 1/2 in Stock Status NONSTOCK Brand Sandvik Coromant Manufacturer Sandvik Coromant Chipbreaker ZZ Inscribed Circle 1/2 in Insert Size 1203 Insert Style SBEX Manufacturer's Grade H13A Material Carbide Material Grade K Rake Neutral Shape Square 90 deg major cutting edge 0.315 in L effective cutting edge 0.004 to 0.017 in cutting feed 45 deg corner chamfer 0.022 in W corner chamfer 20 life cycle state
content loaded
content loaded
content loaded
- Attributes
- Features
- Substitute Products
| ANSI Code | SBEX 12 03 ZZ H13A |
| Catalog Number | 5780215 |
| Corner Radius | 0.02 in |
| Country of Origin | JP |
| Finish | Uncoated |
| Gross Weight Per Pack | 0.1800 lb |
| Hand of Insert | Neutral |
| ISO Code | SBEX 12 03 ZZ H13A |
| Lead Angle | 5 ° |
| Length | 1/2 in |
| Material Application | Cast Iron |
| Series | Auto FS |
| Thickness | 1/8 in |
| Width | 1/2 in |
| Stock Status | NONSTOCK |
| Brand | Sandvik Coromant |
| Manufacturer | Sandvik Coromant |
| Chipbreaker | ZZ |
| Inscribed Circle | 1/2 in |
| Insert Size | 1203 |
| Insert Style | SBEX |
| Manufacturer's Grade | H13A |
| Material | Carbide |
| Material Grade | K |
| Rake | Neutral |
| Shape | Square |
| 90 deg major cutting edge |
| 0.315 in L effective cutting edge |
| 0.004 to 0.017 in cutting feed |
| 45 deg corner chamfer |
| 0.022 in W corner chamfer |
| 20 life cycle state |
