Sandvik Coromant 5747652 Century Milling Insert, R590-110504H-NL H10 ANSI, C-80 deg Diamond, R/L590..H..L Insert, Carbide, H10
Custom_Product_Images_Illustration
Sandvik Coromant 5747652 Century Milling Insert, R590-110504H-NL H10 ANSI, C-80 deg Diamond, R/L590..H..L Insert, Carbide, H10
SKU80703
MFGR #5747652
Your Cost: $25.79/ea
List: Sandvik Coromant Milling Insert, Series: Century, R/L590..H..L Insert, C-80 deg Diamond, 0.453 in Inscribed Circle, 0.1968 in Thickness, 0.4527 in Width, 0.5118 in Length, NL Chipbreaker, 0.0157 in Corner Radius, 25 deg Positive Rake, 90 deg Lead Angle, 0.1811 in Hole Dia, Manufacturer's Grade: H10, ANSI Code: R590-110504H-NL H10, ISO Code: R590-110504H-NL H10, Right Hand, Carbide, Uncoated, Material Grade: N
Sandvik Coromant Milling Insert, Series: Century, R/L590..H..L Insert, C-80 deg Diamond, 0.453 in Inscribed Circle, 0.1968 in Thickness, 0.4527 in Width, 0.5118 in Length, NL Chipbreaker, 0.0157 in Corner Radius, 25 deg Positive Rake, 90 deg Lead Angle, 0.1811 in Hole Dia, Manufacturer's Grade: H10, ANSI Code: R590-110504H-NL H10, ISO Code: R590-110504H-NL H10, Right Hand, Carbide, Uncoated, Material Grade: N
Alternate Catalog Number R590-110504H-NL H10 ANSI Code R590-110504H-NL H10 Catalog Number 5747652 Corner Radius 0.0157 in Country of Origin SE Finish Uncoated Gross Weight Per Pack 0.1600 lb Hand of Insert Right Hole Diameter 0.1811 in ISO Code R590-110504H-NL H10 Item Group 350 Lead Angle 90 ° Material Application Non-Ferrous Metals Series CoroMill® Century Thickness 0.197 in UPC 11 69826220251 UPC 12 69826220251 Width 0.453 in Stock Status NONSTOCK Brand Sandvik Coromant Manufacturer Sandvik Coromant Chipbreaker NL Inscribed Circle 0.453 in Insert Size 110504 Insert Style R/L590..H..L Manufacturer's Grade H10 Material Carbide Material Grade N Shape Proprietary 40 - 60 deg countersunk hole and non-flat surface clamping interface 10 mm D cutting 2 mm L wiper edge 200 mm wiper edge radius 90 deg major cutting edge 11 mm L effective cutting edge 1-side cutting 20 life cycle state 2 corner F cutting edge condition 2 cutting edge Screw clamp mounting 0.1 - 0.4 mm/r cutting feed
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | R590-110504H-NL H10 |
| ANSI Code | R590-110504H-NL H10 |
| Catalog Number | 5747652 |
| Corner Radius | 0.0157 in |
| Country of Origin | SE |
| Finish | Uncoated |
| Gross Weight Per Pack | 0.1600 lb |
| Hand of Insert | Right |
| Hole Diameter | 0.1811 in |
| ISO Code | R590-110504H-NL H10 |
| Item Group | 350 |
| Lead Angle | 90 ° |
| Material Application | Non-Ferrous Metals |
| Series | CoroMill® Century |
| Thickness | 0.197 in |
| UPC 11 | 69826220251 |
| UPC 12 | 69826220251 |
| Width | 0.453 in |
| Stock Status | NONSTOCK |
| Brand | Sandvik Coromant |
| Manufacturer | Sandvik Coromant |
| Chipbreaker | NL |
| Inscribed Circle | 0.453 in |
| Insert Size | 110504 |
| Insert Style | R/L590..H..L |
| Manufacturer's Grade | H10 |
| Material | Carbide |
| Material Grade | N |
| Shape | Proprietary |
| 40 - 60 deg countersunk hole and non-flat surface clamping interface |
| 10 mm D cutting |
| 2 mm L wiper edge |
| 200 mm wiper edge radius |
| 90 deg major cutting edge |
| 11 mm L effective cutting edge |
| 1-side cutting |
| 20 life cycle state |
| 2 corner |
| F cutting edge condition |
| 2 cutting edge |
| Screw clamp mounting |
| 0.1 - 0.4 mm/r cutting feed |
