Sandvik Coromant 5734678 Milling Insert, LPMH 25 06 10-MM 2040 ANSI, L-Rectangle, LPMH-MM Insert, Carbide, 2040
LPMH Milling Inserts
1252611
MFG #: 5734678
Sandvik Coromant
37.51000
/ ea
- Alternate Catalog Number: LPMH 25 06 10-MM 2040
- ANSI Code: LPMH 25 06 10-MM 2040
- Catalog Number: 5734678
- Corner Radius: 0.0393 in
- Country of Origin: SE
- Finish: MTCVD Coated
- Gross Weight Per Pack: 0.0500 lb
- Hand of Insert: Right
- Hole Diameter: 0.2165 in
- Included Angle: 6.35 mm
- Includes: 14.2748 mm
- ISO Code: LPMH 25 06 10-MM 2040
- Item Group: 350
- Lead Angle: 90 deg
- Length: 90 deg
- Series: LPMH 25 06 10-MM 2040
- Thickness: 1/4 in
- Type: LPMH-MM
- UPC 11: 69826217887
- Width: 0.562 in
- Stock Status: NONSTOCK
- Brand: Sandvik Coromant
- Manufacturer: Sandvik Coromant
- Chipbreaker: MM
- Inscribed Circle: 0.562 in
- Insert Size: 5.5 mm
- Insert Style: LPMH-MM
- Manufacturer's Grade: 2040
- Material: Carbide
- Material Grade: M/P
- Rake: Positive
- Shape: L-Rectangle
Sandvik Coromant Milling Insert, LPMH-MM Insert, L-Rectangle, 0.562 in Inscribed Circle, 1/4 in Thickness, 0.562 in Width, MM Chipbreaker, 0.0393 in Corner Radius, Positive Rake, 90 deg Lead Angle, 0.2165 in Hole Dia, Manufacturer's Grade: 2040, ANSI Code: LPMH 25 06 10-MM 2040, ISO Code: LPMH 25 06 10-MM 2040, Right Hand, Carbide, MTCVD Coated, Material Grade: M/P
- Features
| 40 to 60 deg countersunk hole and non-flat surface clamping interface |
| 11 deg clearance |
| 90 deg included |
| 21.59 mm L effective cutting edge |
| 1-side cutting |
| 20 life cycle state |
| 2 corner |
| E cutting edge condition |
| 2 cutting edge |
| Screw clamp mounting |
| 0.05 to 0.2 mm/r cutting feed |
