Turck
Turck BI15-CP40-FZ3X2 Inductive Sensor, Programmable Output, 1NO/1NC, 20 to 250 VAC/10 to 300 VDC
Turck
Turck BI15-CP40-FZ3X2 Inductive Sensor, Programmable Output, 1NO/1NC, 20 to 250 VAC/10 to 300 VDC
SKU38590
MFGR #13410
Your Cost: $271.44/ea
List: Inductive Sensor, Rectangular, height 40 mm, Variable orientation of active face in 9 directions, Plastic, PBT-GF30-V0, High luminance corner LEDs, Optimum view on supply voltage and switching state from any position, AC 2-wire, 20…250 VDC, DC 2-wire, 10…300 VDC, NC/NO programmable, Terminal chamber, Rated switching distance: 15 mm, Flush
Inductive Sensor, Rectangular, height 40 mm, Variable orientation of active face in 9 directions, Plastic, PBT-GF30-V0, High luminance corner LEDs, Optimum view on supply voltage and switching state from any position, AC 2-wire, 20…250 VDC, DC 2-wire, 10…300 VDC, NC/NO programmable, Terminal chamber, Rated switching distance: 15 mm, Flush
Amperage Rating 400/300 mA Catalog Number 13410 Connection Type Terminal Chamber Country of Origin DE Cut~off Size 0.02 kHz Frequency Response 0.02 kHz Gross Weight Per Pack 0.5800 lb Gross Weight per Pack Metric 230.00 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536507000 Material Plastic Measuring Range 400/300 mA Mounting Type Flush Resolution 114 mm L x 40 mm W x 40 mm H Returnable Y Sensing Distance 15 mm Sensing Position Terminal Chamber Series 15 mm Size 114 mm L x 40 mm W x 40 mm H Temperature Rating -25 to 70 deg C Type 20 to 250 VAC/10 to 300 VDC UPC 11 66289013410 Stock Status NORMALLY STOCKED Brand Turck Manufacturer Turck, Inc. Contact Configuration 1NO/1NC Output Type Programmable Sensing Method Programmable Voltage Rating 20 to 250 VAC/10 to 300 VDC Rectangular, height 40 mm, Variable orientation of active face in 9 directions, Plastic, PBT-GF30-V0, High luminance corner LEDs, Optimum view on supply voltage and switching state from any position, AC 2-wire, 20…250 VDC, DC 2-wire, 10…300 VDC, NC/NO programmable, Terminal chamber Rectangular design Black finished housing IEC IP67 protection class 1 LED (green) power on indication 1 LED (red) switching state indication 2-wire AC/DC circuit Optimum view on supply voltage and switching state from any position Variable orientation of active face in 9 directions High switching frequency
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Amperage Rating | 400/300 mA |
| Catalog Number | 13410 |
| Connection Type | Terminal Chamber |
| Country of Origin | DE |
| Cut~off Size | 0.02 kHz |
| Frequency Response | 0.02 kHz |
| Gross Weight Per Pack | 0.5800 lb |
| Gross Weight per Pack Metric | 230.00 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536507000 |
| Material | Plastic |
| Measuring Range | 400/300 mA |
| Mounting Type | Flush |
| Resolution | 114 mm L x 40 mm W x 40 mm H |
| Returnable | Y |
| Sensing Distance | 15 mm |
| Sensing Position | Terminal Chamber |
| Series | 15 mm |
| Size | 114 mm L x 40 mm W x 40 mm H |
| Temperature Rating | -25 to 70 deg C |
| Type | 20 to 250 VAC/10 to 300 VDC |
| UPC 11 | 66289013410 |
| Stock Status | NORMALLY STOCKED |
| Brand | Turck |
| Manufacturer | Turck, Inc. |
| Contact Configuration | 1NO/1NC |
| Output Type | Programmable |
| Sensing Method | Programmable |
| Voltage Rating | 20 to 250 VAC/10 to 300 VDC |
| Rectangular, height 40 mm, Variable orientation of active face in 9 directions, Plastic, PBT-GF30-V0, High luminance corner LEDs, Optimum view on supply voltage and switching state from any position, AC 2-wire, 20…250 VDC, DC 2-wire, 10…300 VDC, NC/NO programmable, Terminal chamber |
| Rectangular design |
| Black finished housing |
| IEC IP67 protection class |
| 1 LED (green) power on indication |
| 1 LED (red) switching state indication |
| 2-wire AC/DC circuit |
| Optimum view on supply voltage and switching state from any position |
| Variable orientation of active face in 9 directions |
| High switching frequency |
