Siemens LEN00C003120B Lighting Contactor, 110/120 VAC Coil, 30 A Max Load, 3NO, 3 Poles
Lighting Contactors
678003
MFG #: LEN00C003120B
Siemens
217.71000
/ ea
- Alternate Catalog Number: US2:LEN00C003120B
- ARRA Compliant: C
- Buy American Compliant: C
- Catalog Number: LEN00C003120B
- Coil Power Rating: 87 VA Pickup, 9.4 VA Holding
- Connection Type: Screw
- Contact Type: Non-Combination
- Country of Origin: DE
- Currency: USD
- Dimensions: 3.47 in H x 1.84 in W x 3.96 in D
- Enclosure Type: Open
- EU RoHS Indicator: C
- Frequency Rating: 50/60 Hz
- Gross Volume Per Pack: 34.19
- Gross Volume UOM: in
- Gross Weight Per Pack: 1.0000 lb
- Gross Weight per Pack Metric: 0.45
- Gross Weight UOM Metric: kg
- Harmonization Tariff Schedule Code: 8536490065
- Height: 4.20 in
- Height [Metric]: 10.6680 cm
- Length: 3.70 in
- Length [Metric]: 9.3980 cm
- Mounting Type: Surface
- Number of Auxiliary Contacts: 4
- Operating Temperature: 0 to 40
- Returnable: Y
- Standards: ARRA, Buy American Act and RoHS Compliant
- UNSPSC: 39121529
- UPC 11: 04089285981
- UPC 12: 040892859812
- Width: 2.20 in
- Width [Metric]: 5.5880 cm
- Stock Status: NORMALLY STOCKED
- Brand: Siemens
- Manufacturer: Siemens
- Coil Voltage: 110/120 VAC
- Contact Configuration: 3NO
- Maximum Load Current: 30 A
- Number Of Poles: 3
SIEMENS LEN00C003120B CONTACTOR LTG EH OPEN 30A 3NO 120V
- Brochure URL - LEN00C003120B.pdf(Brochure URL)
- Catalog URL - Siemens_14CUC32BA_Catalog.pdf(Catalog URL)
- Computer~Aided [CAD|BIM] Model URL - 2D_G_IC03_XX_19590V.pdf(Computer~Aided [CAD|BIM] Model URL)
- http://www.sea.siemens.com(Seller Home Page URL)
- Spec Sheet 1 URL - Siemens_LEN00C003120B_Specification_Sheet.pdf(Spec Sheet 1 URL)
- Spec Sheet URL - DatasheetService?format=PDF&caller=PDPS&mlfbs=US2:LEN00C003120B&language=en(Spec Sheet URL)
- Spec Sheet URL - LEN00C003120B.pdf(Spec Sheet URL)
- User Manual URL - man(User Manual URL)
- Wiring Diagram URL - WD_G_IC03_XX_20208V.pdf(Wiring Diagram URL)
- Features
| Electrically held operational mode |
| Copper material of the conductor for supply, load side outgoing feeder and at magnet coil |
