nVent HOFFMAN C20C20 C5 Series Consolet Enclosure, 20 in L x 20 in W x 13.09 in D, NEMA 12/13/IP65 NEMA Rating, Steel
Console & Consolet Enclosures
25651
MFG #: C20C20
nVent HOFFMAN
570.26000
/ ea
- Application: Controls and Drives
- ARRA Compliant: C
- Assemble to Order: No
- Buy American Compliant: C
- Catalog Number: C20C20
- Color: Gray
- Color Code: ANSI 61
- Country of Origin: MX
- Currency: USD
- EU RoHS Indicator: C
- Finish: Powder Coat
- Gross Volume Per Pack: 3.99
- Gross Volume UOM: FC
- Gross Weight Per Pack: 36.0000 lb
- Gross Weight per Pack Metric: 15.47
- Gross Weight UOM Metric: kg
- Harmonization Tariff Schedule Code: 7326908688
- Height [Metric]: 35.8140 cm
- Interchangeable: No
- IP Rating: IP65
- Item Group: C5
- Length [Metric]: 62.7380 cm
- Modification Services: Yes
- Package Quantity: 1
- Returnable: Y
- Shipping Weight: 36 lb
- Size: 20.00x20.00x13.09 in
- Standards: UL 508A Listed, Type 12, 13, File No. E61997, cUL Listed per CSA C22.2 No. 94, Type 12, 13, File No. E61997, NEMA/EEMAC Type 12, 13 , CSA File Number 42186: Type 12, IEC 60529, IP65,, RoHS Complaint
- Thickness: 14 ga
- Thickness [Metric]: 1.9 mm
- Type: HMI Enclosure Systems
- UNSPSC: 39121323
- UPC 11: 78351059900
- UPC 12: 783510599003
- Width [Metric]: 50.2920 cm
- Stock Status: NONSTOCK
- Brand: nVent HOFFMAN
- Manufacturer: HOFFMAN ENCLOSURES
- Depth: 13.09
- Height: 14.10 in
- Length: 24.70 in
- Material: Mild Steel
- NEMA Rating: 12 Indoor, dust-resistant
- Width: 19.80 in
- http://www.hoffmanonline.com(Seller Home Page URL)
- Install Instructions 1 URL - 11015_9KDB1L2EVXUOW584.pdf(Install Instructions 1 URL)
- Install Instructions 1 URL - stream_document.aspx?rRID=19277&pRID=6759(Install Instructions 1 URL)
- Install Instructions URL - stream_document.aspx?rRID=19277&pRID=6759(Install Instructions URL)
- Spec Sheet URL - Spec-00356.pdf(Spec Sheet URL)
- Tech Drawing URL - C2760-C.gif(Tech Drawing URL)
- Warranty URL - terms-of-sale(Warranty URL)
- Applications
- Features
Controls and Drives |
14 gauge steel , Seams continuously welded and ground smooth; no holes or knockouts, Captivated cover screws thread into sealed wells, Bonding provision on cover, Oil-resistant gasket and adhesive, Control panel attached with continuous hinge along bottom edge |
14 ga steel body |
Seams continuously welded and ground smooth, no holes or knockouts |
Captivated cover screws thread into sealed wells |
Bonding provision on cover |
Oil-resistant gasket and adhesive |
Control panel attached with continuous hinge along bottom edge |
