nVent HOFFMAN AWDH1612N4 A80W Deep Hinged Window Kit, 10.68 in H x 3.41 in W, 14.19 in H x 8.14 in W x 2.73 in D, Steel, Medium Gray, Polyester Powder Painted
Enclosure Window Kits
713540
MFG #: AWDH1612N4
nVent HOFFMAN
1136.57000
/ ea
- Accessory Type: Window Kits
- Application: Controls and Drives; Power Distribution
- ARRA Compliant: C
- Assemble to Order: No
- Buy American Compliant: C
- Catalog Number: AWDH1612N4
- Color Code: ANSI 61
- Country of Origin: US
- Currency: USD
- EU RoHS Indicator: Y
- Gross Volume Per Pack: 0.77
- Gross Volume UOM: FC
- Gross Weight Per Pack: 8.2200 lb
- Gross Weight per Pack Metric: 3.86
- Gross Weight UOM Metric: kg
- Harmonization Tariff Schedule Code: 7326908688
- Height: 6.25 in
- Height [Metric]: 15.8750 cm
- Interchangeable: No
- IP Rating: IP66
- Item Group: A80W
- Length: 17.88 in
- Length [Metric]: 45.4152 cm
- Modification Services: Yes
- NEMA Rating: 4 Watertight
- Package Quantity: 1
- Returnable: Y
- Shipping Weight: 8 lb
- Size: 14.19 x 8.14 in
- Standards: cUL Listed per CSA C22.2 E61997, EU Certified, IEC 60529, IP66, RoHS Compliant, UL 508A E61997
- Thickness: 14 ga
- Thickness [Metric]: 1.9 mm
- Type: Industrial Door Mounting and Locks
- UNSPSC: 39121321
- UPC 11: 78351013005
- UPC 12: 783510130053
- Width: 11.88 in
- Width [Metric]: 30.1752 cm
- Window Size [Metric]: 271 x 87 mm
- Stock Status: NONSTOCK
- Brand: nVent HOFFMAN
- Manufacturer: HOFFMAN ENCLOSURES
- Color: Gray
- Finish: Powder Coated
- Material: Mild Steel
- Window Size: 10.68 x 3.41 in
nVent HOFFMAN Window Kit, Deep Hinged, Series: A80W, 10.68 in H x 3.41 in W Window, 14.19 in H x 8.14 in W x 2.73 in D, NEMA 4/4X/12/IP66, Steel, Polyester Powder Painted, Medium Gray
- http://www.hoffmanonline.com(Seller Home Page URL)
- Install Instructions 1 URL - 11015_ENWYMCAH83QS7VGZ.pdf(Install Instructions 1 URL)
- Install Instructions URL - stream_document.aspx?rRID=19597&pRID=6698(Install Instructions URL)
- Spec Sheet 1 URL - Hoffman_AWDH1418N4_Specification_Sheet.pdf(Spec Sheet 1 URL)
- Spec Sheet URL - Spec-00477.pdf(Spec Sheet URL)
- Tech Drawing URL - 87948405.gif(Tech Drawing URL)
- Warranty URL - terms-of-sale(Warranty URL)
- Applications
- Features
| Controls and Drives; Power Distribution |
| Manufactured from Type 316L stainless steel or painted mild steel, Quarter-turn latches for quick access, 0.25-in. (6-mm) thick, clear polycarbonate windows for easy viewing, 2.5-in. (64-mm) deep to allow for deep controls, Built-in gasket compression stop on back of window kit facilitates flush mounting, Designed for either left or right hinging, Includes mounting template and mounting hardware, Easy-to-remove clip-style hinge pin |
| Quarter turn latches for quick access |
| 1/4 in THK, clear polycarbonate windows for easy viewing |
| 2.5 in deep to allow for deep controls |
| Built in gasket compression stop on back of window kit facilitates flush mounting |
| Designed for either left or right hinging |
| Easy to remove clip style hinge pins |
