Hubbell Wiring Device-Kellems HBLB7NFD26AA NONFUSED HAZ LOC
Hazardous Location Disconnect Switches
731045
MFG #: HBLB7NFD26AA
Hubbell Wiring Device-Kellems
4014.16000
/ ea
- Action: Snap
- Actuator: Lever
- Actuator Type: Lockable Handle
- Application: Extra Heavy Duty Industrial
- ARRA Compliant: C
- Buy American Compliant: C
- Catalog Number: HBLB7NFD26AA
- Color: Gray
- Connection: Terminal Screws
- Contact Configuration: Two Position
- Contact Rating: 60A
- Country of Origin: US
- Currency: USD
- Dimensions: 13.06 in L x 8.13 in W x 7.81 in H
- Enclosure: Metallic
- Enclosure Type: NEMA 4X
- Environmental Conditions: Indoors or Outdoors or Hazardous Atmosphere
- EU RoHS Indicator: N
- Finish: Powder Polyester Painted
- Frequency Rating: 60 Hz
- Gross Weight Per Pack: 23.3000 lb
- Gross Weight per Pack Metric: 10.57
- Gross Weight UOM Metric: kg
- Harmonization Tariff Schedule Code: 8536509025
- Height: 10.90 in
- Height [Metric]: 27.6860 cm
- Length: 14.90 in
- Length [Metric]: 37.8460 cm
- Material: Aluminum, Copper Free (less than 4/10 of 1%)
- Mounting: Mounting Feet
- Mounting Type: Feet/Snap
- Operating Temperature: Max Continuous- 67 Degrees C, Minimum- -40 Without Impact
- Returnable: Y
- Size: 13.06 in x 8.13 in x 7.81 in
- Standard: UL98 Certified
- Standards: ARRA CompliantBuy American Act CompliantUL File No. 746C/98OSHA ApprovedCSA Certified
- Sub Brand: Circuit-Lock
- Switch Type: Lever
- Temperature Rating: -40 to 67 °C
- Terminal Type: Screw
- Type: Switch with Aux Contact
- UNSPSC: 39122205
- UPC 11: 78358524263
- UPC 12: 78358524263
- Wattage: 36 kW
- Width: 10.40 in
- Width [Metric]: 26.4160 cm
- Stock Status: NONSTOCK
- Brand: Hubbell Wiring Device-Kellems
- Manufacturer: Hubbell
- Amperage Rating: 60 A
- Contact Form: 2-Auxiallary/1NO
- Horsepower: 40 hp
- Voltage Rating: 600 V
- Number Of Poles: 3
Hubbell's hazardous location unfused disconnect and mechanical interlock switches are ideal for applications with the presence of flammable gases or vapors, or ignitable dusts and fibers. They are also suitable for use in outdoor or indoor damp, wet and dirty locations or in areas where frequent wash downs, heavy rain or water spray routinely occurs. Compact in size to reduce cost over industry standard sizes, these switches are easy to position on the wall or piece of equipment. The enclosures are made of copper free aluminum and have a polyester/epoxy finish to prevent corrosion. The high visibility handles can be locked to meet OSHA lockout/tag out regulations.
- Catalog URL - Wiring_Device_Kellems_HBLB7NFD13AA_Catalog.pdf(Catalog URL)
- http://www.hubbell-wiring.com/(Seller Home Page URL)
- Install Instructions 1 URL - 11456_RIFCHJQGEY7VXDO9.pdf(Install Instructions 1 URL)
- Install Instructions 1 URL - WIRING_KIL00921328_INSTALLINST.pdf(Install Instructions 1 URL)
- Spec Sheet URL - 11456_11503915-SPE-EN-1.pdf(Spec Sheet URL)
- Spec Sheet URL - 11503915-SPE-EN-1.pdf(Spec Sheet URL)
- Spec Sheet URL - WIRING_HBLB7NFD26AA_spec.pdf(Spec Sheet URL)
- Warranty URL - 11456_Y8PS6T0FNOGH3Q75.pdf(Warranty URL)
- Warranty URL - Wiring_WDK_Warranty.pdf(Warranty URL)
- Applications
- Features
| Extra Heavy Duty Industrial |
| Hazardous Locations, With Aux Contact |
| Hazardous locations, with aux contact |
| Large visible rotary handle with ON/OFF indicator |
| Compact NEMA 4X enclosure and footprint allows easy installation in tight locations |
| Gasketed flange with O-ring located inside bolt circle to seal out moisture |
| Rotary handle style operating mechanism with lockout provision |
