Square D™ M9F15302 Multi 9™ C60N Curve D Miniature Circuit Breaker, 240/415/440 VAC, 125 VDC, 2 A, 40 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Square D™ M9F15302 Multi 9™ C60N Curve D Miniature Circuit Breaker, 240/415/440 VAC, 125 VDC, 2 A, 40 kA Interrupt, 3 Poles, Thermal Magnetic Trip
SKUPDW~11743114
MFGR #M9F15302
Price Not Available
Schneider Electric Square D™ Miniature Circuit Breaker, Curve D, Series: Multi 9™ C60N, 240/415/440 VAC, 125 VDC, 2 A, 50/60 Hz Frequency, 40 kA Interrupt, Thermal Magnetic Trip, 3 Poles, Toggle Actuator, Flexible/Rigid Tunnel Connection, IP20/IP40 Enclosure, Clip-On/DIN Rail Mounting, -30 to 70 deg C, 54 mm W x 72 mm D x 81 mm H Dimensions, Gray
Schneider Electric Square D™ Miniature Circuit Breaker, Curve D, Series: Multi 9™ C60N, 240/415/440 VAC, 125 VDC, 2 A, 50/60 Hz Frequency, 40 kA Interrupt, Thermal Magnetic Trip, 3 Poles, Toggle Actuator, Flexible/Rigid Tunnel Connection, IP20/IP40 Enclosure, Clip-On/DIN Rail Mounting, -30 to 70 deg C, 54 mm W x 72 mm D x 81 mm H Dimensions, Gray
Actuator Toggle Alternate Catalog Number M9F15302 Application Distribution ARRA Compliant N Buy American Compliant N Catalog Number M9F15302 Connection Tunnel type terminal top or bottom) 1-25 mm² - rigid;tunnel type terminal top or bottom) 1-25 mm² - flexible;tunnel type terminal top or bottom) 1-25 mm² - flexible with ferrule Country of Origin FR Currency USD EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Weight Per Pack 0.7700 lb Gross Weight per Pack Metric 348.42 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536200040 Height 3.1496 in Height [Metric] 7.5000 cm Item Group 00908 Length 3.1496 in Length [Metric] 8.5000 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=244804344&lang=en-us Number Of Poles 3 Returnable N Standard EN/IEC 60947-2;EAC;CCC Sub Brand Multi9 C60;C60H Substitute Product Catalog Number A9XPH306 Type Miniature circuit-breaker UNSPSC 39121603 Width 1.9685 in Width [Metric] 5.4000 cm Brand Square D™ Manufacturer Schneider Electric Trip Type Thermal-magnetic Distribution ON/OFF indication
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator | Toggle |
| Alternate Catalog Number | M9F15302 |
| Application | Distribution |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | M9F15302 |
| Connection | Tunnel type terminal top or bottom) 1-25 mm² - rigid;tunnel type terminal top or bottom) 1-25 mm² - flexible;tunnel type terminal top or bottom) 1-25 mm² - flexible with ferrule |
| Country of Origin | FR |
| Currency | USD |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.7700 lb |
| Gross Weight per Pack Metric | 348.42 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 3.1496 in |
| Height [Metric] | 7.5000 cm |
| Item Group | 00908 |
| Length | 3.1496 in |
| Length [Metric] | 8.5000 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=244804344&lang=en-us |
| Number Of Poles | 3 |
| Returnable | N |
| Standard | EN/IEC 60947-2;EAC;CCC |
| Sub Brand | Multi9 C60;C60H |
| Substitute Product Catalog Number | A9XPH306 |
| Type | Miniature circuit-breaker |
| UNSPSC | 39121603 |
| Width | 1.9685 in |
| Width [Metric] | 5.4000 cm |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Trip Type | Thermal-magnetic |
| Distribution |
| ON/OFF indication |
